GT5E-1P-DS(71)

Active

Hirose Electric USA, Inc.

CONN COAX RCPT R/A 50 OHM PCB

Search across all available documentation for this part.

Active

Hirose Electric USA, Inc.

CONN COAX RCPT R/A 50 OHM PCB

Technical Specifications

Parameters and characteristics for this part

Specification	GT5E-1P-DS(71)

Body Material	Nylon, Polyamide (PA)
Center Contact Material	Brass
Center Contact Plating	Tin
Connector Style	Coaxial
Connector Type	Male Pin, Receptacle
Contact Termination	Solder
Dielectric Material	Polybutylene Terephthalate (PBT)
Fastening Type	Push-Pull
Frequency - Max [Max]	2 GHz
Housing Color	Natural
Impedance	50 Ohms
Mating Cycles	30
Mounting Type	Through Hole, Right Angle
Number of Ports	1
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-30 ░C
Voltage Rating	250 VDC

Part	Dielectric Material	Center Contact Material	Housing Color	Contact Termination	Mounting Type	Voltage Rating	Frequency - Max [Max]	Connector Style	Connector Type	Impedance	Center Contact Plating	Body Material	Operating Temperature [Min]	Operating Temperature [Max]	Number of Ports	Fastening Type	Mating Cycles
Hirose Electric USA, Inc. GT5E-1P-DS(70)	Polybutylene Terephthalate (PBT)	Brass	Natural	Solder	Through Hole Right Angle	250 VDC	2 GHz	Coaxial	Male Pin Receptacle	50 Ohms	Tin	Nylon Polyamide (PA)	-30 ░C	105 ░C	1	Push-Pull	30
Hirose Electric USA, Inc. GT5E-1P-DS(71)	Polybutylene Terephthalate (PBT)	Brass	Natural	Solder	Through Hole Right Angle	250 VDC	2 GHz	Coaxial	Male Pin Receptacle	50 Ohms	Tin	Nylon Polyamide (PA)	-30 ░C	105 ░C	1	Push-Pull	30

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Coaxial Connector Receptacle, Male Pin 50 Ohms Through Hole, Right Angle Solder
