GSID200A120S5C1

Obsolete

SemiQ

IGBT MODULE 1200V 335A

Search across all available documentation for this part.

Obsolete

SemiQ

IGBT MODULE 1200V 335A

Technical Specifications

Parameters and characteristics for this part

Specification	GSID200A120S5C1

Configuration	Three Phase Inverter
Current - Collector (Ic) (Max) [Max]	335 A
Current - Collector Cutoff (Max) [Max]	1 mA
Input	Standard
Input Capacitance (Cies) @ Vce	22.4 nF
Mounting Type	Chassis Mount
NTC Thermistor	True
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-40 °C
Package / Case	Module
Supplier Device Package	Module
Vce(on) (Max) @ Vge, Ic	2.1 V
Voltage - Collector Emitter Breakdown (Max) [Max]	1200 V

Part	Current - Collector Cutoff (Max) [Max]	Input	Configuration	Voltage - Collector Emitter Breakdown (Max) [Max]	Package / Case	Mounting Type	Current - Collector (Ic) (Max) [Max]	Input Capacitance (Cies) @ Vce	Operating Temperature [Max]	Operating Temperature [Min]	Vce(on) (Max) @ Vge, Ic	Supplier Device Package	NTC Thermistor
SemiQ GSID200A120S5C1	1 mA	Standard	Three Phase Inverter	1200 V	Module	Chassis Mount	335 A	22.4 nF	150 °C	-40 °C	2.1 V	Module

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

IGBT Module Three Phase Inverter 1200 V 335 A Chassis Mount Module
