PC375-2C-12S4-X
ActivePicker Components
RELAY GEN PURPOSE DPDT 16A 12V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PC375-2C-12S4-X
ActivePicker Components
RELAY GEN PURPOSE DPDT 16A 12V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PC375-2C-12S4-X |
|---|---|
| Coil Current | 34.2 mA |
| Coil Insulation | Class F |
| Coil Resistance | 351 Ohms |
| Coil Type | Non Latching |
| Coil Voltage | 12 VDC |
| Contact Form | DPDT (2 Form C) |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Contact Rating (Current) | 8 A |
| Load - Max Switching | 6080 VA, 1760 W |
| Mounting Type | Through Hole |
| Must Operate Voltage | 8.4 VDC |
| Must Release Voltage | 1.2 VDC |
| Operate Time | 15 ms |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Relay Type | General Purpose |
| Release Time | 8 ms |
| Seal Rating | Sealed - Fully |
| Switching Voltage | 110 VDC, 380 VAC |
| Termination Style | PC Pin |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 2.81 | |
| 10 | $ 2.45 | |||
| 30 | $ 2.30 | |||
| 50 | $ 2.23 | |||
| 100 | $ 2.14 | |||
| 250 | $ 2.03 | |||
| 500 | $ 1.95 | |||
| 1000 | $ 1.87 | |||
| 5000 | $ 1.70 | |||
Description
General part information
PC375-2C Series
General Purpose Relay DPDT (2 Form C) 12VDC Coil Through Hole
Documents
Technical documentation and resources
