1-2176085-0
ActiveTE Connectivity Passive Product
RES 330 OHM 5% 9W AXIAL
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
1-2176085-0
ActiveTE Connectivity Passive Product
RES 330 OHM 5% 9W AXIAL
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 1-2176085-0 |
|---|---|
| Composition | Wirewound |
| Features | Pulse Withstanding, Flame Retardant Coating, Safety |
| Number of Terminations | 2 |
| Operating Temperature [Max] | 155 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Axial |
| Power (Watts) | 9 W |
| Resistance | 330 Ohms |
| Size / Dimension [diameter] | 8.5 mm |
| Size / Dimension [diameter] | 0.335 " |
| Size / Dimension [x] | 1.575 in |
| Size / Dimension [x] | 40 mm |
| Supplier Device Package | Axial |
| Temperature Coefficient | 300 ppm/°C |
| Tolerance | 5 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 75 | $ 0.96 | |
| 450 | $ 0.93 | |||
Description
General part information
2176085 Series
330 Ohms ±5% 9W Through Hole Resistor Axial Flame Retardant Coating, Pulse Withstanding, Safety Wirewound
