9CRA0824P8G001
ActiveSanyo Denki America Inc.
FAN AXIAL DUAL 80X80MM 24VDC
Deep-Dive with AI
Search across all available documentation for this part.
9CRA0824P8G001
ActiveSanyo Denki America Inc.
FAN AXIAL DUAL 80X80MM 24VDC
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 9CRA0824P8G001 |
|---|---|
| Air Flow | 158.9 CFM |
| Air Flow | 4.45 m³/min |
| Approval Agency | cURus, TUV |
| Bearing Type | Ball |
| Current Rating (Amps) | 2.65 A |
| Fan Type | Tubeaxial (Dual) |
| Lifetime @ Temp. | 40000 Hrs |
| Material - Blade | Plastic |
| Material - Frame | Plastic |
| Noise | 76 dB(A) |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -20 °C |
| Operating Temperature [Min] | -20 C |
| Power (Watts) | 63.6 W |
| Size / Dimension [x] | 80 mm |
| Size / Dimension [y] | 80 mm |
| Static Pressure | 4.62 in H2O |
| Static Pressure | 1150.8 Pa |
| Termination | 4 Wire Leads per Fan |
| Voltage - Rated | 24 VDC |
| Voltage Range [Max] | 26.4 VDC |
| Voltage Range [Min] | 21.6 VDC |
| Weight | 450.42 g |
| Weight | 0.993 lb |
| Width [y] | 80 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 96.47 | |
| 12 | $ 86.70 | |||
| 36 | $ 85.48 | |||
| 60 | $ 79.98 | |||
| 108 | $ 78.15 | |||
Description
General part information
9CRA0824 Series
Fan Tubeaxial (Dual) 24VDC Square - 80mm L x 80mm H Ball 158.9 CFM (4.45m³/min) 4 Wire Leads per Fan
