4014B
ActiveHeyco Products Corporation
LTB 30-50/PG7 BLACK
Deep-Dive with AI
Search across all available documentation for this part.
4014B
ActiveHeyco Products Corporation
LTB 30-50/PG7 BLACK
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 4014B |
|---|---|
| Bushing, Grommet Type | Grommet |
| Color | Black |
| Diameter - Inside [Max] [diameter] | 0.2 " |
| Diameter - Inside [Max] [diameter] | 5.08 mm |
| Diameter - Inside [Min] [diameter] | 3.05 mm |
| Diameter - Inside [Min] [diameter] | 0.12 " |
| For Use With/Related Products | Wires, Cable |
| Material | Ethylene Propylene Terpolymer Rubber (EPDM) |
| Panel Thickness [Max] | 0.16 in |
| Panel Thickness [Max] | 4.06 mm |
| Panel Thickness [Min] | 0.04 in |
| Panel Thickness [Min] | 1.02 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 0.97 | |
| 5 | $ 0.81 | |||
| 10 | $ 0.73 | |||
| 25 | $ 0.65 | |||
| 50 | $ 0.58 | |||
| 100 | $ 0.56 | |||
| 250 | $ 0.55 | |||
| 600 | $ 0.53 | |||
| 1200 | $ 0.48 | |||
Description
General part information
4014 Series
Circular - 0.519" (13.18mm) Grommet 0.120" ~ 0.200" (3.05mm ~ 5.08mm) Black
Documents
Technical documentation and resources
No documents available
