WP26-P054VA1-R15000
ObsoleteJAE Electronics
CONN PLUG 54POS SMD GOLD
Deep-Dive with AI
Search across all available documentation for this part.
WP26-P054VA1-R15000
ObsoleteJAE Electronics
CONN PLUG 54POS SMD GOLD
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | WP26-P054VA1-R15000 |
|---|---|
| Connector Type | Outer Shroud Contacts, Plug |
| Contact Finish | Gold |
| Contact Finish Thickness | 4 Áin |
| Contact Finish Thickness | 0.1 Ám |
| Features | Solder Retention |
| Height Above Board [z] | 0.48 mm |
| Height Above Board [z] | 0.019 " |
| Mated Stacking Heights | 0.6 mm |
| Mounting Type | Surface Mount |
| Number of Positions | 54 |
| Number of Rows | 2 |
| Pitch [x] | 0.35 mm |
| Pitch [x] | 0.014 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 1.21 | |
| 10 | $ 1.04 | |||
| 25 | $ 0.97 | |||
| 50 | $ 0.92 | |||
| 100 | $ 0.90 | |||
Description
General part information
WP26-P05 Series
54 Position Connector Plug, Outer Shroud Contacts Surface Mount Gold
