ALC70A181DD630

Active

KEMET

CAP ALUM 180UF 20% 630V SNAP TH

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsALC70A181DD630 Spec KEM_A4081_ALC70.pdf +1

ALC70A181DD630

Active

KEMET

CAP ALUM 180UF 20% 630V SNAP TH

Deep-Dive with AI

DocumentsALC70A181DD630 Spec KEM_A4081_ALC70.pdf +1

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	ALC70A181DD630

Applications	General Purpose
Capacitance	180 çF
ESR (Equivalent Series Resistance)	727.3 mOhm
Height - Seated (Max) [Max]	42 mm
Height - Seated (Max) [Max]	1.654 in
Impedance	501 mOhms
Lead Spacing	0.394 in
Lead Spacing	10 mm
Lifetime @ Temp.	15000 Hrs
Mounting Type	Through Hole
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	Radial, Can - Snap-In
Polarization	Polar
Ripple Current @ High Frequency	3.89 A
Ripple Current @ Low Frequency	1.79 A
Size / Dimension [diameter]	1.378 in
Size / Dimension [diameter]	35 mm
Tolerance	20 %
Voltage - Rated	630 V

ALC70A Series

Part	Polarization	Impedance	Package / Case	Size / Dimension [diameter]	Size / Dimension [diameter]	Ripple Current @ High Frequency	Voltage - Rated	Lead Spacing	Lead Spacing	Ripple Current @ Low Frequency	Lifetime @ Temp.	Operating Temperature [Max]	Operating Temperature [Min]	Applications	Mounting Type	Capacitance	Tolerance	ESR (Equivalent Series Resistance)	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
KEMET ALC70A361EB450	Polar	231 mOhms	Radial Can - Snap-In	1.575 "	40 mm	4.56 A	450 V	0.394 in	10 mm	2.1 A	18000 Hrs	85 °C	-40 °C	General Purpose	Through Hole	360 µF	20 %	405 mOhm
KEMET ALC70A132DF250	Polar	85 mOhms	Radial Can - Snap-In	1.378 in	35 mm	7.33 A	250 V	0.394 in	10 mm	3.71 A	15000 Hrs	85 °C	-40 °C	General Purpose	Through Hole	1300 µF	20 %	145 mOhm	2.047 in	52 mm
KEMET ALC70A912BD040	Polar	69 mOhms	Radial Can - Snap-In	0.984 "	25 mm		40 V	0.394 in	10 mm	4.21 A	10000 Hrs	85 °C	-40 °C	General Purpose	Through Hole	9100 µF	20 %	83.38 mOhm			42 mm	1.654 in
KEMET ALC70A511EF550	Polar	749 mOhms	Radial Can - Snap-In	1.575 "	40 mm	4.05 A	550 V	0.394 in	10 mm	2.64 A	18000 Hrs	85 °C	-40 °C	General Purpose	Through Hole	510 µF	20 %	860 mOhm	2.047 in	52 mm
KEMET ALC70A472CB063	Polar	61 mOhms	Radial Can - Snap-In	1.181 inches	30 mm	6.15 A	63 V	0.394 in	10 mm	4.3 A	13000 Hrs	85 °C	-40 °C	General Purpose	Through Hole	4700 µF	20 %	81.08 mOhm
KEMET ALC70A181DD630	Polar	501 mOhms	Radial Can - Snap-In	1.378 in	35 mm	3.89 A	630 V	0.394 in	10 mm	1.79 A	15000 Hrs	85 °C	-40 °C	General Purpose	Through Hole	180 çF	20 %	727.3 mOhm			42 mm	1.654 in
KEMET ALC70A151DC600	Polar	589 mOhms	Radial Can - Snap-In	1.378 in	35 mm	3.46 A		0.394 in	10 mm	1.6 A	15000 Hrs	85 °C	-40 °C	General Purpose	Through Hole	150 µF	20 %	852.6 mOhm	1.457 in	37 mm
KEMET ALC70A752CD063	Polar	39 mOhms	Radial Can - Snap-In	1.181 inches	30 mm		63 V	0.394 in	10 mm	5.72 A	13000 Hrs	85 °C	-40 °C	General Purpose	Through Hole	7500 µF	20 %	52 mOhm			42 mm	1.654 in
KEMET ALC70A102EL500	Polar	150 mOhms	Radial Can - Snap-In	1.575 "	40 mm	8.53 A	500 V	0.394 in	10 mm	4.42 A	18000 Hrs	85 °C	-40 °C	General Purpose	Through Hole	1000 µF	20 %	209.2 mOhm	3.228 in	82 mm
KEMET ALC70A332DC100	Polar	67 mOhms	Radial Can - Snap-In	1.378 in	35 mm	6.47 A	100 V	0.394 in	10 mm	4.89 A	15000 Hrs	85 °C	-40 °C	General Purpose	Through Hole	3.3 mF	20 %	83.9 mOhm	1.457 in	37 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 10.90
		10	$ 9.45
		100	$ 7.36
		1000	$ 6.18

Description

General part information

ALC70A Series

180 µF 630 V Aluminum Electrolytic Capacitors Radial, Can - Snap-In 727.3mOhm @ 100Hz 15000 Hrs @ 85°C

Documents

Technical documentation and resources

ALC70A181DD630 Spec

Datasheet

KEM_A4081_ALC70.pdf

Datasheet
