SR11-3V-200-2C
ActiveCUI Devices
RELAY GENERAL PURPOSE DPDT 1A 3V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
SR11-3V-200-2C
ActiveCUI Devices
RELAY GENERAL PURPOSE DPDT 1A 3V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SR11-3V-200-2C |
|---|---|
| Coil Current | 66.7 mA |
| Coil Resistance | 45 Ohms |
| Coil Type | Non Latching |
| Contact Form | DPDT (2 Form C) |
| Contact Material | Silver (Ag), Gold (Au) |
| Contact Rating (Current) | 1 A |
| Load - Max Switching | 120 VA, 24 W |
| Mounting Type | Through Hole |
| Must Operate Voltage | 2.25 VDC |
| Must Release Voltage | 0.3 VDC |
| Operate Time | 7 ms |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -25 °C |
| Relay Type | General Purpose |
| Release Time | 3 ms |
| Switching Voltage [Max] | 24 VDC, 120 VAC |
| Termination Style | PC Pin |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 1.15 | |
| 10 | $ 1.07 | |||
| 25 | $ 0.95 | |||
| 50 | $ 0.91 | |||
| 100 | $ 0.86 | |||
| 250 | $ 0.84 | |||
Description
General part information
SR11-3V Series
General Purpose Relay DPDT (2 Form C) Through Hole
