LCY CLBP-KZLY-5F5G-8E8G-350-S

Obsolete

ams-OSRAM USA INC.

LED OSLON SIGNAL YELLOW SMD

Search across all available documentation for this part.

Obsolete

ams-OSRAM USA INC.

LED OSLON SIGNAL YELLOW SMD

Technical Specifications

Parameters and characteristics for this part

Specification	LCY CLBP-KZLY-5F5G-8E8G-350-S

Color	Yellow
Current - Max [Max]	1 A
Current - Test	350 mA
Height - Seated (Max) [Max]	1.77 mm
Height - Seated (Max) [Max]	0.069 in
Lumens/Watt @ Current - Test	120 lm/W
Luminous Flux @ Current/Temperature	124
Mounting Type	Surface Mount
Package / Case	1212
Package / Case	3030 Metric
Size / Dimension [x]	0.118 in
Size / Dimension [x]	3 mm
Size / Dimension [y]	3 mm
Size / Dimension [y]	0.118 in
Supplier Device Package	SMD
Viewing Angle	125 °
Voltage - Forward (Vf) (Typ)	2.95 V

Part	Current - Test	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Luminous Flux @ Current/Temperature [Min]	Luminous Flux @ Current/Temperature	Luminous Flux @ Current/Temperature [Max]	Color	Lumens/Watt @ Current - Test	Voltage - Forward (Vf) (Typ)	Thermal Resistance of Package [custom]	Mounting Type	Package / Case	Package / Case	Viewing Angle	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Current - Max [Max]	Supplier Device Package	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
ams-OSRAM USA INC. LCY CLBP-KXKZ-5F5G-1-350-R18-Z	350 mA	0.118 in	3 mm	3 mm	0.118 in	71 lm	92 lm	112 lm	Yellow	89 lm/W	2.95 V	9.6 °C/W	Surface Mount	1212	3030 Metric	125 °	1.77 mm	0.07 in	1 A	SMD
ams-OSRAM USA INC. LCY CLBP-KZLY-5F5G-8E8G-350-S	350 mA	0.118 in	3 mm	3 mm	0.118 in		124		Yellow	120 lm/W	2.95 V		Surface Mount	1212	3030 Metric	125 °			1 A	SMD	1.77 mm	0.069 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

LED Lighting Color OSLON® Signal Yellow 1212 (3030 Metric)
