CA12P-5

Active

XP POWER

DC DC CONVERTER 1250V 1W

Search across all available documentation for this part.

Active

XP POWER

DC DC CONVERTER 1250V 1W

Technical Specifications

Parameters and characteristics for this part

Specification	CA12P-5

Applications	ITE (Commercial)
Current - Output (Max) [Max]	800 µA
Features	SCP
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max] [custom]	50 °C
Operating Temperature [Min] [custom]	-10 °C
Package / Case	8-DIP Module
Size / Dimension [x]	44.5 mm
Size / Dimension [x]	1.75 "
Size / Dimension [y]	1.1 in
Size / Dimension [y]	27.9 mm
Size / Dimension [z]	0.5 in
Size / Dimension [z]	12.7 mm
Standard Number	62368-1
Type	High Voltage - Non-Isolated Module
Voltage - Input (Max) [Max]	5.25 V
Voltage - Input (Min) [Min]	4.75 V
Voltage - Output 1	1250 V

Part	Operating Temperature [Min] [custom]	Operating Temperature [Max] [custom]	Applications	Voltage - Output 1	Mounting Type	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Voltage - Input (Max) [Max]	Current - Output (Max) [Max]	Standard Number	Number of Outputs	Package / Case	Type	Features	Voltage - Input (Min) [Min]
XP POWER CA12P-5	-10 °C	50 °C	ITE (Commercial)	1250 V	Through Hole	44.5 mm	1.1 in	1.75 "	0.5 in	12.7 mm	27.9 mm	5.25 V	800 µA	62368-1	1	8-DIP Module	High Voltage - Non-Isolated Module	SCP	4.75 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

High Voltage - Non-Isolated Module DC DC Converter 1 Output 1250V 800µA 4.75V - 5.25V Input
