PESE1-S5-D24-M-TR

CUI Inc.

DC DC CONVERTER +/-24V 1W

Deep-Dive with AI

Search across all available documentation for this part.

PESE1-S5-D24-M-TR

CUI Inc.

DC DC CONVERTER +/-24V 1W

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	PESE1-S5-D24-M-TR

Applications	ITE (Commercial)
Approval Agency	CB Scheme, IEC, EN
Current - Output (Max) [Max]	21 mA
Current - Output (Max) [Min]	21 mA
Efficiency	85 %
Features	SCP
Mounting Type	Surface Mount
Number of Outputs	2
Operating Temperature [Max]	105 C
Operating Temperature [Min]	-40 °C
Package / Case	10-SMD Module, 6 Leads
Size / Dimension [x]	0.6 in
Size / Dimension [x]	15.2 mm
Size / Dimension [y]	0.33 in
Size / Dimension [y]	8.5 mm
Size / Dimension [z]	7.3 mm
Size / Dimension [z]	0.29 "
Standard Number	62368-1, 55024, 55032 Class A
Type	Isolated Module
Voltage - Input (Max) [Max]	5.5 V
Voltage - Input (Min) [Min]	4.5 V
Voltage - Isolation	3000 V
Voltage - Output 1	24 V
Voltage - Output 2	-24 V

PESE1 Series

Part	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Package / Case	Voltage - Input (Max) [Max]	Current - Output (Max)	Voltage - Input (Min) [Min]	Voltage - Output 2	Features	Type	Approval Agency	Standard Number	Applications	Voltage - Output 1	Efficiency	Number of Outputs	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Voltage - Isolation	Current - Output (Max) [Max]	Current - Output (Max) [Max]	Current - Output (Max) [Min]
CUI Inc. PESE1-S5-D15-M	7.3 mm	0.6 in	0.33 in	15.2 mm	0.29 "	8.5 mm	10-SMD Module 6 Leads	5.5 V	34 mA	4.5 V	-15 V	SCP	Isolated Module	CB Scheme EN IEC	55024 55032 Class A 62368-1	ITE (Commercial)	15 V	83 %	2	-40 °C	105 C	Surface Mount	3000 V
CUI Inc. PESE1-S5-S15-M-TR	0.29 "	13.2 mm	8.5 mm	0.52 "	7.3 mm	0.33 "	8-SMD Module 5 Leads	5.5 V		4.5 V		SCP	Isolated Module	CB Scheme EN IEC UL	55024 55032 Class A 62368-1	ITE (Commercial)	15 V	83 %	1	-40 °C	105 C	Surface Mount	3000 V	67 mA
CUI Inc. PESE1-S5-S5-M-TR	0.29 "	13.2 mm	8.5 mm	0.52 "	7.3 mm	0.33 "	8-SMD Module 5 Leads	5.5 V		4.5 V		SCP	Isolated Module	CB Scheme EN IEC UL	55024 55032 Class A 62368-1	ITE (Commercial)	5 V		1	-40 °C	105 C	Surface Mount	3000 V	200 mA
CUI Inc. PESE1-S5-S3-M-TR	0.29 "	13.2 mm	8.5 mm	0.52 "	7.3 mm	0.33 "	8-SMD Module 5 Leads	5.5 V		4.5 V		SCP	Isolated Module	CB Scheme EN IEC UL	55024 55032 Class A 62368-1	ITE (Commercial)	3.3 V	74 %	1	-40 °C	105 C	Surface Mount	3000 V	303 mA
CUI Inc. PESE1-S5-S24-M-TR	0.29 "	13.2 mm	8.5 mm	0.52 "	7.3 mm	0.33 "	8-SMD Module 5 Leads	5.5 V		4.5 V		SCP	Isolated Module	CB Scheme EN IEC UL	55024 55032 Class A 62368-1	ITE (Commercial)	24 V	85 %	1	-40 °C	105 C	Surface Mount	3000 V	42 mA
CUI Inc. PESE1-S5-S15-M	0.29 "	13.2 mm	8.5 mm	0.52 "	7.3 mm	0.33 "	8-SMD Module 5 Leads	5.5 V		4.5 V		SCP	Isolated Module	CB Scheme EN IEC UL	55024 55032 Class A 62368-1	ITE (Commercial)	15 V	83 %	1	-40 °C	105 C	Surface Mount	3000 V	67 mA
CUI Inc. PESE1-S5-D9-M-TR	7.3 mm	0.6 in	0.33 in	15.2 mm	0.29 "	8.5 mm	10-SMD Module 6 Leads	5.5 V		4.5 V	-9 V	SCP	Isolated Module	CB Scheme EN IEC	55024 55032 Class A 62368-1	ITE (Commercial)	9 V	83 %	2	-40 °C	105 C	Surface Mount	3000 V
CUI Inc. PESE1-S5-S5-M	0.29 "	13.2 mm	8.5 mm	0.52 "	7.3 mm	0.33 "	8-SMD Module 5 Leads	5.5 V		4.5 V		SCP	Isolated Module	CB Scheme EN IEC UL	55024 55032 Class A 62368-1	ITE (Commercial)	5 V		1	-40 °C	105 C	Surface Mount	3000 V	200 mA
CUI Inc. PESE1-S5-D12-M-TR	7.3 mm	0.6 in	0.33 in	15.2 mm	0.29 "	8.5 mm	10-SMD Module 6 Leads	5.5 V		4.5 V	-12 V	SCP	Isolated Module	CB Scheme EN IEC	55024 55032 Class A 62368-1	ITE (Commercial)	12 V	83 %	2	-40 °C	105 C	Surface Mount	3000 V	42 mA	42 mA
CUI Inc. PESE1-S5-D24-M-TR	7.3 mm	0.6 in	0.33 in	15.2 mm	0.29 "	8.5 mm	10-SMD Module 6 Leads	5.5 V		4.5 V	-24 V	SCP	Isolated Module	CB Scheme EN IEC	55024 55032 Class A 62368-1	ITE (Commercial)	24 V	85 %	2	-40 °C	105 C	Surface Mount	3000 V	21 mA		21 mA

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	500	$ 3.11

Description

General part information

PESE1 Series

Isolated Module DC DC Converter 2 Output 24V -24V 21mA, 21mA 4.5V - 5.5V Input
