0350230015

Active

Molex

CONN BOARD-IN HSG 15POS 2.00MM

Search across all available documentation for this part.

Active

Molex

CONN BOARD-IN HSG 15POS 2.00MM

Technical Specifications

Parameters and characteristics for this part

Part	Number of Rows	Contact Type	Connector Type	Operating Temperature [Min]	Operating Temperature [Max]	Color	Mounting Type	Note	Contact Termination	Number of Positions	Insulation Material	Pitch [x]	Pitch [x]
Molex 0350230004	1	Male Pin	Board-In	-40 °C	105 ░C	Natural	Through Hole Right Angle	Contacts Not Included	Crimp	4	Polyamide (PA66) Nylon 6/6	0.079 in	2 mm
Molex 0350230007	1	Male Pin	Board-In	-40 °C	105 ░C	Natural	Through Hole Right Angle	Contacts Not Included	Crimp	7	Polyamide (PA66) Nylon 6/6	0.079 in	2 mm
Molex 0350230002	1	Male Pin	Board-In	-40 °C	105 ░C	Natural	Through Hole Right Angle	Contacts Not Included	Crimp	2	Polyamide (PA66) Nylon 6/6	0.079 in	2 mm
Molex 0350230008	1	Male Pin	Board-In	-40 °C	105 ░C	Natural	Through Hole Right Angle	Contacts Not Included	Crimp	8	Polyamide (PA66) Nylon 6/6	0.079 in	2 mm
Molex 0350230005	1	Male Pin	Board-In	-40 °C	105 ░C	Natural	Through Hole Right Angle	Contacts Not Included	Crimp		Polyamide (PA66) Nylon 6/6	0.079 in	2 mm
Molex 0350230013	1	Male Pin	Board-In	-40 °C	105 ░C	Natural	Through Hole Right Angle	Contacts Not Included	Crimp	13	Polyamide (PA66) Nylon 6/6	0.079 in	2 mm
Molex 0350230009	1	Male Pin	Board-In	-40 °C	105 ░C	Natural	Through Hole Right Angle	Contacts Not Included	Crimp	9	Polyamide (PA66) Nylon 6/6	0.079 in	2 mm
Molex 0350230015	1	Male Pin	Board-In	-40 °C	105 ░C	Natural	Through Hole Right Angle	Contacts Not Included	Crimp	15	Polyamide (PA66) Nylon 6/6	0.079 in	2 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	15000	$ 0.15

General part information

15 Rectangular Connectors - Housings Board-In Natural 0.079" (2.00mm)
