7183-1HV

Active

BRADY

B946 WHT/BLU STYLE 1HV MEDICAL A

Search across all available documentation for this part.

Active

BRADY

B946 WHT/BLU STYLE 1HV MEDICAL A

Technical Specifications

Parameters and characteristics for this part

Specification	7183-1HV

Application Specifics	Compressed Air
Applications	Medical
Arrangement	Text Only
Color - Background	Blue
Color - Legend	White
Features	Chemical Resistant, Weather Resistant, Abrasion Resistant
Language	English
Legend (Symbol Only)	False
Legend (Text)	Medical Air
Length [x]	24 in
Length [x]	609.6 mm
Location	Outdoor
Material - Body	Vinyl
Mounting Type	Adhesive
Outside Pipe Diameter (Max) [Max] [diameter]	203.2 mm
Outside Pipe Diameter (Max) [Max] [diameter]	8 "
Print Type	Pre-Printed
Shape	Rectangle
Width [x]	4 "
Width [x]	101.6 mm

Part	Material - Body	Legend (Symbol Only)	Outside Pipe Diameter (Max) [Max] [diameter]	Outside Pipe Diameter (Max) [Max] [diameter]	Application Specifics	Length [x]	Length [x]	Color - Background	Width [x]	Width [x]	Color - Legend	Shape	Applications	Mounting Type	Legend (Text)	Arrangement	Features	Location	Print Type	Language
BRADY 7183-1HV	Vinyl		203.2 mm	8 "	Compressed Air	24 in	609.6 mm	Blue	4 "	101.6 mm	White	Rectangle	Medical	Adhesive	Medical Air	Text Only	Abrasion Resistant Chemical Resistant Weather Resistant	Outdoor	Pre-Printed	English

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 7.77

General part information

B946 WHT/BLU STYLE 1HV MEDICAL A
