PRPC034DFBN-RC

Active

Sullins Connector Solutions

CONN HEADER VERT 68POS 2.54MM

Deep-Dive with AI

Search across all available documentation for this part.

PRPC034DFBN-RC

Active

Sullins Connector Solutions

CONN HEADER VERT 68POS 2.54MM

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	PRPC034DFBN-RC

Connector Type	Breakaway, Header
Contact Finish - Mating	Gold
Contact Finish - Post	Gold
Contact Finish Thickness - Mating	Flash
Contact Finish Thickness - Post	Flash
Contact Length - Mating [x]	0.318 "
Contact Length - Mating [x]	8.08 mm
Contact Length - Post	0.22 in
Contact Length - Post	5.58 mm
Contact Material	Brass
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	3 A
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height [z]	0.098 in
Insulation Height [z]	2.5 mm
Insulation Material	Polybutylene Terephthalate (PBT)
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	68
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Overall Contact Length	16.17 mm
Overall Contact Length	0.637 in
Pitch - Mating	0.1 in
Pitch - Mating	2.54 mm
Row Spacing - Mating [x]	2.54 mm
Row Spacing - Mating [x]	0.1 in
Shrouding	Unshrouded
Style	Board to Board, Cable
Termination	Solder

PRPC034 Series

Part	Number of Positions Loaded	Style	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Material Flammability Rating	Contact Shape	Contact Length - Post [x]	Contact Length - Post [x]	Pitch - Mating	Pitch - Mating	Contact Length - Mating [x]	Contact Length - Mating [x]	Fastening Type	Insulation Color	Termination	Number of Rows	Insulation Material	Contact Material	Contact Finish - Mating	Current Rating (Amps)	Connector Type	Shrouding	Contact Finish - Post	Contact Finish Thickness - Post	Number of Positions	Insulation Height [z]	Insulation Height [z]	Contact Type	Contact Finish Thickness - Mating	Contact Length - Mating	Overall Contact Length	Overall Contact Length	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Overall Contact Length	Contact Length - Post	Contact Length - Post
Sullins Connector Solutions PRPC034SGAN-M71RC	All	Board to Board Cable	-40 °C	105 ░C	Through Hole Right Angle	UL94 V-0	Square	0.12 in	3.05 mm	0.1 in	2.54 mm	0.318 "	8.08 mm	Push-Pull	Black	Solder	1	Polybutylene Terephthalate (PBT)	Brass	Gold	3 A	Breakaway Header	Unshrouded	Gold	Flash	34	0.098 in	2.5 mm	Male Pin	Flash
Sullins Connector Solutions PRPC034SAAN-RC	All	Board to Board Cable	-40 °C	105 ░C	Through Hole	UL94 V-0	Square	0.12 in	3.05 mm	0.1 in	2.54 mm	0.23 in		Push-Pull	Black	Solder	1	Polybutylene Terephthalate (PBT)	Brass	Gold	3 A	Breakaway Header	Unshrouded	Gold	Flash	34	0.098 in	2.5 mm	Male Pin	Flash	5.84 mm	0.448 in	11.39 mm
Sullins Connector Solutions PRPC034DAAN-RC	All	Board to Board Cable	-40 °C	105 ░C	Through Hole	UL94 V-0	Square	0.12 in	3.05 mm	0.1 in	2.54 mm	0.23 in		Push-Pull	Black	Solder	2	Polybutylene Terephthalate (PBT)	Brass	Gold	3 A	Breakaway Header	Unshrouded	Gold	Flash	68	0.098 in	2.5 mm	Male Pin	Flash	5.84 mm	0.448 in	11.39 mm	2.54 mm	0.1 in
Sullins Connector Solutions PRPC034SFAN-RC	All	Board to Board Cable	-40 °C	105 ░C	Through Hole	UL94 V-0	Square	0.12 in	3.05 mm	0.1 in	2.54 mm	0.318 "	8.08 mm	Push-Pull	Black	Solder	1	Polybutylene Terephthalate (PBT)	Brass	Gold	3 A	Breakaway Header	Unshrouded	Gold	Flash	34	0.098 in	2.5 mm	Male Pin	Flash			0.537 "			13.63 mm
Sullins Connector Solutions PRPC034DFAN-RC	All	Board to Board Cable	-40 °C	105 ░C	Through Hole	UL94 V-0	Square	0.12 in	3.05 mm	0.1 in	2.54 mm	0.318 "	8.08 mm	Push-Pull	Black	Solder	2	Polybutylene Terephthalate (PBT)	Brass	Gold	3 A	Breakaway Header	Unshrouded	Gold	Flash	68	0.098 in	2.5 mm	Male Pin	Flash			0.537 "	2.54 mm	0.1 in	13.63 mm
Sullins Connector Solutions PRPC034SACN-RC	All	Board to Board Cable	-40 °C	105 ░C	Through Hole	UL94 V-0	Square	0.32 in	8.13 mm	0.1 in	2.54 mm	0.23 in		Push-Pull	Black	Solder	1	Polybutylene Terephthalate (PBT)	Brass	Gold	3 A	Breakaway Header	Unshrouded	Gold	Flash	34	0.098 in	2.5 mm	Male Pin	Flash	5.84 mm	0.648 in	16.47 mm
Sullins Connector Solutions PRPC034DFBN-RC	All	Board to Board Cable	-40 °C	105 ░C	Through Hole	UL94 V-0	Square			0.1 in	2.54 mm	0.318 "	8.08 mm	Push-Pull	Black	Solder	2	Polybutylene Terephthalate (PBT)	Brass	Gold	3 A	Breakaway Header	Unshrouded	Gold	Flash	68	0.098 in	2.5 mm	Male Pin	Flash		0.637 in	16.17 mm	2.54 mm	0.1 in		0.22 in	5.58 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 2.24
		10	$ 1.71
		100	$ 1.32
		500	$ 1.11
		1000	$ 1.03
		5000	$ 0.98

Description

General part information

PRPC034 Series

Connector Header Through Hole 68 position 0.100" (2.54mm)
