AMEL12-24SCJZ
Activeaimtec
AC/DC CONVERTER 24V 12W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AMEL12-24SCJZ
Activeaimtec
AC/DC CONVERTER 24V 12W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AMEL12-24SCJZ |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) [Max] | 500 mA |
| Efficiency | 83 % |
| Features | Universal Input |
| Line Regulation | 0.5 % |
| Load Regulation | 0.5 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -25 °C |
| Package / Case | 4-DIP Module |
| Power (Watts) | 12 W |
| Size / Dimension [x] | 53.8 mm |
| Size / Dimension [x] | 2.12 " |
| Size / Dimension [y] | 1.13 in |
| Size / Dimension [y] | 28.8 mm |
| Size / Dimension [z] | 0.93 in |
| Size / Dimension [z] | 23.5 mm |
| Type | Enclosed |
| Voltage - Output 1 | 24 V |
| Weight | 60 g |
| Weight | 0.132 lb |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
AMEL12 Series
Enclosed AC DC Converters 1 Output 24V 500mA 85 ~ 264 VAC Input
