PLED75W-012

Active

Thomas Research Products

LED DRIVER CV AC/DC 12V 6.25A

Search across all available documentation for this part.

Active

Thomas Research Products

LED DRIVER CV AC/DC 12V 6.25A

Technical Specifications

Parameters and characteristics for this part

Part	Current - Output (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Efficiency	Voltage - Input (Max) [Max]	Number of Outputs	Ratings	Approval Agency	Voltage - Output [Min]	Voltage - Output [Max]	Termination Style	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Voltage - Input (Min) [Min]	Mounting Type	Power (Watts)	Type	Features	Topology	Voltage - Output
Thomas Research Products PLED75W-036-C2100	2.1 A	65 °C	-30 ░C	89 %	305 VAC	1	IP66 NEMA 6	CE cULus	12 V	36 V	Wire Leads	1.47 in	5.12 "	37.3 mm	2.33 in	130 mm	59.2 mm	90 VAC	Chassis Mount	75 W	Constant Current	OCP OVP SCP	AC DC Converter
Thomas Research Products PLED75W-012	6.25 A	65 °C	-30 ░C	86 %	305 VAC	1	IP66 NEMA 6	CE cULus			Wire Leads	1.47 in	5.12 "	37.3 mm	2.33 in	130 mm	59.2 mm	90 VAC	Chassis Mount	75 W	Constant Voltage	OCP OVP SCP	AC DC Converter	12 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	500	$ 88.35

General part information

6.25A 12V Constant Voltage LED Driver AC DC Converter Topology 1 Output

Technical documentation and resources
