Technical Specifications
Parameters and characteristics for this part
| Specification | 10GX52F 0081000 |
|---|---|
| Cable Type | Multi-Pair, Cat6a |
| Conductor Insulation | Polyolefin (PO) |
| Conductor Material | Copper, Bare |
| Conductor Strand | Solid |
| Features | Rip Cord, Drain Wire |
| Jacket (Insulation) Diameter [diameter] | 6.99 mm |
| Jacket (Insulation) Diameter [diameter] | 0.275 in |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC), Riser |
| Jacket Color | Gray |
| Length | 1000 ft |
| Length | 304.8 m |
| Number of Conductors | 8 |
| Ratings | UL Style CMR |
| Shield Coverage | 100 % |
| Shield Material | Polyester, Aluminum |
| Shield Type | Foil |
| Usage | Network |
| Voltage | 300 V |
| Wire Gauge | 23 AWG |
10GX52F Series
| Part | Length | Length | Voltage | Cable Type | Number of Conductors | Jacket Color | Conductor Material | Jacket (Insulation) Material | Shield Type | Conductor Insulation | Shield Coverage | Conductor Strand | Ratings | Wire Gauge | Features | Shield Material | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Usage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Belden Inc. | 1000 ft | 304.8 m | 300 V | Multi-Pair Cat6a | 8 | Red | Copper Bare | Poly-Vinyl Chloride (PVC) Riser | Foil | Polyolefin (PO) | 100 % | Solid | UL Style CMR | 23 AWG | Drain Wire Rip Cord | Aluminum Polyester | 6.99 mm | 0.275 in | Network |
Belden Inc. | 1000 ft | 304.8 m | 300 V | Multi-Pair Cat6a | 8 | Black | Copper Bare | Poly-Vinyl Chloride (PVC) Riser | Foil | Polyolefin (PO) | 100 % | Solid | UL Style CMR | 23 AWG | Drain Wire Rip Cord | Aluminum Polyester | 6.99 mm | 0.275 in | Network |
Belden Inc. | 1000 ft | 304.8 m | 300 V | Multi-Pair Cat6a | 8 | Gray | Copper Bare | Poly-Vinyl Chloride (PVC) Riser | Foil | Polyolefin (PO) | 100 % | Solid | UL Style CMR | 23 AWG | Drain Wire Rip Cord | Aluminum Polyester | 6.99 mm | 0.275 in | Network |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Spool | 1000 | $ 0.86 | |
Description
General part information
10GX52F Series
8 (4 Pair) Conductor Multi-Pair, Cat6a Cable Gray 23 AWG Foil 1000.0' (304.8m)
