1093 X 1/2"

Obsolete

3M (TC)

TAPE ELECTRICAL AMBER 1/2"X36YDS

Search across all available documentation for this part.

Obsolete

3M (TC)

TAPE ELECTRICAL AMBER 1/2"X36YDS

Technical Specifications

Parameters and characteristics for this part

Part	Width [x]	Width [x]	Usage	Adhesive	Temperature Range	Temperature Range	Thickness - Adhesive	Thickness - Adhesive	Thickness - Adhesive	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Length	Length	Length	Tape Type	Color	Thickness	Thickness	Thickness	Backing, Carrier [custom]	Backing, Carrier [custom]	Width	Width	Width
3M (TC) 1093 X 1"	25.4 mm	1 in	Masking High Temperature	Silicone Thermosetting	180 °C	356 °F	1.5 mils	0.0015 in	0.038 mm	1 mils	0.025 mm	0.001 "	36 yd	32.9 m	108 ft	Electrical	Amber	2.5 mils	0.064 mm	0.0025 "	Polyimide Film	Polyimide Film
3M (TC) 1093 X 1/2"			Masking High Temperature	Silicone Thermosetting	180 °C	356 °F	1.5 mils	0.0015 in	0.038 mm	1 mils	0.025 mm	0.001 "	36 yd	32.9 m	108 ft	Electrical	Amber	2.5 mils	0.064 mm	0.0025 "	Polyimide Film	Polyimide Film	0.5 in	12.7 mm	0.5 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Electrical Tape Silicone Thermosetting Adhesive Amber 0.50" (12.70mm) 1/2" X 108' (32.9m) 36 yds
