AMEL60-12SJZ

Active

aimtec

AC/DC CONVERTER 12V 60W

Search across all available documentation for this part.

Active

aimtec

AC/DC CONVERTER 12V 60W

Technical Specifications

Parameters and characteristics for this part

Part	Voltage - Input [Max]	Voltage - Input [Min]	Line Regulation	Number of Outputs	Applications	Power (Watts)	Load Regulation	Current - Output (Max) [Max]	Package / Case	Mounting Type	Features	Type	Efficiency	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Voltage - Output 1
aimtec AMEL60-48SJZ	264 VAC 370 VDC	85 VAC 100 V	0.5 %	1	ITE (Commercial)	60 W	1 %	1.25 A	4-DIP Module	Through Hole	Universal Input	Enclosed	90 %	29.5 mm	3.43 in	52 mm	87 mm	2.05 in	1.16 "	48 V
aimtec AMEL60-24SJZ	264 VAC 370 VDC	85 VAC 100 V	0.5 %	1	ITE (Commercial)	60 W	1 %	2.5 A	4-DIP Module	Through Hole	Universal Input	Enclosed	89 %	29.5 mm	3.43 in	52 mm	87 mm	2.05 in	1.16 "	24 V
aimtec AMEL60-15SJZ	264 VAC 370 VDC	85 VAC 100 V	0.5 %	1	ITE (Commercial)	60 W	1 %	4 A	4-DIP Module	Through Hole	Universal Input	Enclosed	88 %	29.5 mm	3.43 in	52 mm	87 mm	2.05 in	1.16 "	15 V
aimtec AMEL60-12SJZ	264 VAC 370 VDC	85 VAC 100 V	0.5 %	1	ITE (Commercial)	60 W	1 %	5 A	4-DIP Module	Through Hole	Universal Input	Enclosed	87 %	29.5 mm	3.43 in	52 mm	87 mm	2.05 in	1.16 "	12 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Enclosed AC DC Converters 1 Output 12V 5A 85 ~ 264 VAC, 100 ~ 370 VDC Input
