MC-12B-AC120V
ActiveTE Connectivity Raychem Cable Protection
CONTACTOR 3P12A 1 NO/1 NC 120VAC
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MC-12B-AC120V
ActiveTE Connectivity Raychem Cable Protection
CONTACTOR 3P12A 1 NO/1 NC 120VAC
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MC-12B-AC120V |
|---|---|
| Coil Voltage | 120 VAC |
| Contact Form | 3PST-NO (3 Form A) |
| Contact Rating (Current) | 12 A |
| Features | Auxiliary Contacts |
| Mounting Type | Chassis Mount, DIN Rail |
| Operating Temperature [Max] | 40 °C |
| Operating Temperature [Min] | -5 °C |
| Switching Voltage | 600 VAC |
| Termination Style | Screw Terminal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 44.26 | |
| 10 | $ 42.05 | |||
| 25 | $ 39.83 | |||
| 50 | $ 37.62 | |||
| 100 | $ 35.41 | |||
| 250 | $ 33.19 | |||
Description
General part information
MC-12 Series
CONTACTOR 3P12A 1 NO/1 NC 120VAC
Documents
Technical documentation and resources
