109-044UL
ActiveSanyo Denki America Inc.
FAN 80X42MM 230VAC
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsHandling Instructions for Fan Motors
109-044UL
ActiveSanyo Denki America Inc.
FAN 80X42MM 230VAC
Deep-Dive with AI
DocumentsHandling Instructions for Fan Motors
Technical Specifications
Parameters and characteristics for this part
| Specification | 109-044UL |
|---|---|
| Air Flow | 0.988 mł/min |
| Air Flow | 35.3 CFM |
| Approval Agency | CSA, TUV, PSE, UL, CE |
| Bearing Type | Ball |
| Current Rating (Amps) | 50 mA |
| Fan Type | Tubeaxial |
| Lifetime @ Temp. | 25000 Hrs |
| Material - Blade | Plastic |
| Material - Frame | Aluminum |
| Noise | 44 dB |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -30 ░C |
| Operating Temperature [Min] | -30 °C |
| Power (Watts) | 9 W |
| RPM | 3100 RPM |
| Size / Dimension [x] | 80 mm |
| Size / Dimension [y] | 80 mm |
| Static Pressure | 0.142 in H2O |
| Static Pressure | 35.4 Pa |
| Termination | 2 Terminals |
| Voltage - Rated | 230 VAC |
| Weight | 0.904 lb |
| Weight | 410.05 g |
| Width [y] | 42 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 68.38 | |
| 10 | $ 61.87 | |||
| 30 | $ 57.80 | |||
| 60 | $ 56.99 | |||
| 120 | $ 52.51 | |||
Description
General part information
109-044 Series
Fan Tubeaxial 230VAC Square - 80mm L x 80mm H Ball 35.3 CFM (0.988mł/min) 2 Terminals
