LM2594HVM-ADJ
ActiveUMW
IC REG BUCK ADJ 1.5A 8SOP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
LM2594HVM-ADJ
ActiveUMW
IC REG BUCK ADJ 1.5A 8SOP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | LM2594HVM-ADJ |
|---|---|
| Current - Output | 1.5 A |
| Function | Step-Down |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 125 ¯C |
| Operating Temperature [Min] | -40 °C |
| Output Configuration | Positive |
| Output Type | Adjustable |
| Package / Case | 8-SOIC |
| Package / Case [x] | 0.154 in |
| Package / Case [y] | 3.9 mm |
| Supplier Device Package | 8-SOP |
| Synchronous Rectifier | False |
| Topology | Buck |
| Voltage - Input (Min) [Min] | 4.5 V |
| Voltage - Output (Max) | 37 V |
| Voltage - Output (Min/Fixed) | 1.23 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 3.20 | |
| 5 | $ 2.70 | |||
| 10 | $ 2.50 | |||
| 25 | $ 2.27 | |||
| 50 | $ 2.11 | |||
| 100 | $ 1.96 | |||
| 500 | $ 1.66 | |||
| 1000 | $ 1.54 | |||
| Digi-Reel® | 1 | $ 3.20 | ||
| 5 | $ 2.70 | |||
| 10 | $ 2.50 | |||
| 25 | $ 2.27 | |||
| 50 | $ 2.11 | |||
| 100 | $ 1.96 | |||
| 500 | $ 1.66 | |||
| 1000 | $ 1.54 | |||
| Tape & Reel (TR) | 2500 | $ 1.40 | ||
| 5000 | $ 1.30 | |||
| 7500 | $ 1.26 | |||
| Tube | 1 | $ 9.62 | ||
| 10 | $ 6.67 | |||
| 25 | $ 5.91 | |||
| 100 | $ 5.05 | |||
| 250 | $ 4.64 | |||
| 500 | $ 4.39 | |||
Description
General part information
LM2594 Series
Buck Switching Regulator IC Positive Adjustable 1.23V 1 Output 1.5A 8-SOIC (0.154", 3.90mm Width)
