DC1856A-B
ObsoleteAnalog Devices
EVAL BOARD BUCK REG LTM4649
Deep-Dive with AI
Search across all available documentation for this part.
DC1856A-B
ObsoleteAnalog Devices
EVAL BOARD BUCK REG LTM4649
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | DC1856A-B |
|---|---|
| Board Type | Fully Populated |
| Current - Output | 10 A |
| Frequency - Switching | 450 kHz |
| Main Purpose | DC/DC, Step Down |
| Outputs and Type | Non-Isolated |
| Outputs and Type | 1 |
| Regulator Topology | Buck |
| Supplied Contents | Board(s) |
| Utilized IC / Part | LTM4649 |
| Voltage - Input [Max] | 16 V |
| Voltage - Input [Min] | 4.5 V |
| Voltage - Output | 1 V, 1.2 V, 3.3 V, 1.8 V, 1.5 V, 2.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
LTM4649 Series
LTM4649 µModule® DC/DC, Step Down 1, Non-Isolated Outputs Evaluation Board
Documents
Technical documentation and resources
No documents available
