GLM65BG

Obsolete

SL POWER / Advanced Energy

AC/DC CONVERTER 5.1V +/-15V 65W

Search across all available documentation for this part.

Obsolete

SL POWER / Advanced Energy

AC/DC CONVERTER 5.1V +/-15V 65W

Technical Specifications

Parameters and characteristics for this part

Specification	GLM65BG

Applications	Medical
Approval Agency	cURus, CE, TUV
Current - Output 1	7 A
Current - Output 3	2 A
Efficiency	80 %
Features	Remote Sense, Universal Input, Adjustable Output
Minimum Load Required	False
Mounting Type	Chassis Mount
Number of Outputs	3
Size / Dimension [x]	5 in
Size / Dimension [x]	127 mm
Size / Dimension [y]	3 "
Size / Dimension [y]	76.2 mm
Size / Dimension [z]	1.25 "
Size / Dimension [z]	31.8 mm
Type	Open Frame
Voltage - Input [Max]	264 VAC
Voltage - Input [Min]	90 VAC
Voltage - Output 1	5.1 V
Voltage - Output 2	15 V
Voltage - Output 3	-15 V

Part	Applications	Number of Outputs	Voltage - Output 3	Voltage - Output 1	Efficiency	Current - Output 3	Voltage - Input [Min]	Voltage - Input [Max]	Current - Output 1	Approval Agency	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Features	Mounting Type	Voltage - Output 2	Type	Minimum Load Required
SL POWER / Advanced Energy GLM65BG	Medical	3	-15 V	5.1 V	80 %	2 A	90 VAC	264 VAC	7 A	CE cURus TUV	3 "	1.25 "	76.2 mm	5 in	31.8 mm	127 mm	Adjustable Output Remote Sense Universal Input	Chassis Mount	15 V	Open Frame

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Open Frame AC DC Converters 3 Output 5.1V 15V -15V 90 ~ 264 VAC Input
