UT1240-7ZG

Active

EOS Power India Private Ltd

AC/DC CONVERTER 28.25V 500W

Search across all available documentation for this part.

Active

EOS Power India Private Ltd

AC/DC CONVERTER 28.25V 500W

Technical Specifications

Parameters and characteristics for this part

Specification	UT1240-7ZG

Applications	ITE (Commercial)
Approval Agency	cCSAus, CE
Current - Output 1	14.5 A
Efficiency	91 %
Features	Universal Input, Hot Swappable, Adjustable Output, Load Sharing
Mounting Type	Chassis Mount
Number of Outputs	1
Operating Temperature [Max]	71 °C
Operating Temperature [Min]	-25 °C
Power (Watts)	500 W
Size / Dimension [x]	168 mm
Size / Dimension [x]	6.6 "
Size / Dimension [y]	141 mm
Size / Dimension [y]	5.6 "
Size / Dimension [z]	111 mm
Size / Dimension [z]	4.4 in
Type	Conformal Coated, Enclosed
Voltage - Input [Max]	140 VAC
Voltage - Input [Min]	70 VAC
Voltage - Isolation	2.8 kV
Voltage - Output 1	28.25 V

Part	Battery Cell Size	Weight	Voltage - Input [Min]	Voltage - Input [Max]	Charge Current - Max [Max]	Battery Chemistry	Termination Style	Voltage - Nominal	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Mounting Type	Type	Number of Cells	Approval Agency	Operating Temperature [Min]	Operating Temperature [Max]	Power - Max [Max]	Features	Voltage - Output 1	Voltage - Isolation	Efficiency	Number of Outputs	Power (Watts)	Current - Output 1	Applications
EOS Power India Private Ltd UT1240-7Z	24 V	3000 g	85 VAC	255 VAC	14.5 A	Lead Acid	Terminal Block	27.25 V	6.63 "	111 mm	4.4 in	141.5 mm	5.57 "	168.5 mm	DIN Rail	Enclosed	1	cCSAus CE	-25 °C	71 °C	500 W	LED Indicator
EOS Power India Private Ltd UT1240-7ZG			70 VAC	140 VAC					6.6 "	111 mm	4.4 in	141 mm	5.6 "	168 mm	Chassis Mount	Conformal Coated Enclosed		cCSAus CE	-25 °C	71 °C		Adjustable Output Hot Swappable Load Sharing Universal Input	28.25 V	2.8 kV	91 %	1	500 W	14.5 A	ITE (Commercial)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 2041.82

General part information

Enclosed, Conformal Coated AC DC Converters 1 Output 28.25V 70 ~ 140 VAC Input
