NPHS-S6-M-G14
ActiveFesto Corporation
QUICK COUPLING PLUG
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
NPHS-S6-M-G14
ActiveFesto Corporation
QUICK COUPLING PLUG
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | NPHS-S6-M-G14 |
|---|---|
| Connection Method | Threaded |
| Material | Nickel Plated Brass |
| Mounting Type | Free Hanging (In-Line) |
| Operating Pressure [Max] | 145 PSI |
| Operating Pressure [Max] | 10 bar |
| Operating Pressure [Min] | -14 PSI |
| Operating Pressure [Min] | -1 bar |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -10 °C |
| Thread Size | G1/4 |
| Type | Coupling Plug |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 6.09 | |
Description
General part information
NPHS-S6 Series
QUICK COUPLING PLUG
Documents
Technical documentation and resources
