UTG14ST

Active

Souriau-Sunbank by Eaton

CONN BACKSH W/CLMP SZ14 PG13.5

Search across all available documentation for this part.

Active

Souriau-Sunbank by Eaton

CONN BACKSH W/CLMP SZ14 PG13.5

Technical Specifications

Parameters and characteristics for this part

Specification	UTG14ST

Cable Exit	180 °
Cable Opening [Max]	9 mm
Cable Opening [Max]	0.354 in
Cable Opening [Min]	0.236 in
Cable Opening [Min]	6 mm
Color	Black
Diameter - Outside [diameter]	1.062 "
Diameter - Outside [diameter]	26.97 mm
For Use With/Related Products	Trim Trio® UTG and UTP Connectors
Ingress Protection	IP65 - Dust Tight, Water Resistant
Material	Thermoplastic
Shell Size - Insert	14
Thread Size	PG13.5
Type	Backshell, Cable Clamp

Part	Shell Size - Insert	For Use With/Related Products	Thread Size	Material	Color	Diameter - Outside [diameter]	Diameter - Outside [diameter]	Cable Exit	Type	Plating	Features	Cable Opening [Max] [custom]	Cable Opening [Max] [custom]	Cable Opening [Min] [custom]	Cable Opening [Min] [custom]	Includes	Ingress Protection	Cable Opening [Max]	Cable Opening [Min]	Cable Opening [Max]	Cable Opening [Min]
Souriau-Sunbank by Eaton UTG14AD	14	Trim Trio® UTG and UTP Connectors	13/16-20 UNEF	Metal	Black	27 mm	1.063 in	180 °	Backshell Heat Shrink Adapter	Anodized
Souriau-Sunbank by Eaton UTG14PG	14	Trim Trio® UTG and UTP Connectors	PG13.5	Thermoplastic	Black	26.97 mm	1.062 "	180 °	Backshell Cable Clamp		Cable Gland Clamp Screws Washers	0.728 in	18.5 mm	0.276 in	7 mm	1 Backshell 1 Cable Clamp 1 Cable Gland 2 Screws 2 Washers	IP65 - Dust Tight Water Resistant
Souriau-Sunbank by Eaton UTG14ST	14	Trim Trio® UTG and UTP Connectors	PG13.5	Thermoplastic	Black	26.97 mm	1.062 "	180 °	Backshell Cable Clamp								IP65 - Dust Tight Water Resistant	9 mm	0.236 in	0.354 in	6 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Black Connector Backshell, Cable Clamp PG13.5 14
