SRU5011-2R5Y

Obsolete

Bourns Inc.

FIXED IND 2.5UH 1.3A 52 MOHM SMD

Search across all available documentation for this part.

Obsolete

Bourns Inc.

FIXED IND 2.5UH 1.3A 52 MOHM SMD

Technical Specifications

Parameters and characteristics for this part

Part	Current Rating (Amps)	Current - Saturation (Isat)	Material - Core	Mounting Type	Inductance	Tolerance	Shielding	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	DC Resistance (DCR)	Inductance Frequency - Test	Package / Case	Q @ Freq	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Type	Frequency - Self Resonant
Bourns Inc. SRU5011-6R8Y	820 mA	680 mA	Ferrite	Surface Mount	6.8 µH	30 %	Shielded	125 °C	-40 °C	0.205 "	5.2 mm	0.205 in	5.2 mm	130 mOhm	100 kHz	Nonstandard	7.96 MHz 8	1.2 mm	0.047 in	Drum Core Wirewound
Bourns Inc. SRU5011-3R3Y	1.15 A	940 mA	Ferrite	Surface Mount	3.3 µH	30 %	Shielded	125 °C	-40 °C	0.205 "	5.2 mm	0.205 in	5.2 mm	66 mOhm	100 kHz	Nonstandard	7.96 MHz 8	1.2 mm	0.047 in	Drum Core Wirewound	110 MHz
Bourns Inc. SRU5011-2R5Y	1.3 A	1.1 A	Ferrite	Surface Mount	2.5 µH	30 %	Shielded	125 °C	-40 °C	0.205 "	5.2 mm	0.205 in	5.2 mm	52 mOhm	100 kHz	Nonstandard	7.96 MHz 8	1.2 mm	0.047 in	Drum Core Wirewound	125 MHz

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

2.5 µH Shielded Drum Core, Wirewound Inductor 1.3 A 52mOhm Nonstandard
