TEP 200-7216WIRCMF

Active

Traco Power

DC/DC CONVERTER 28V 238W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

TEP 200-7216WIRCMF

Active

Traco Power

DC/DC CONVERTER 28V 238W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	TEP 200-7216WIRCMF

Applications	Railway, ITE (Commercial)
Approval Agency	CB, cURus, CE
Current - Output (Max) [Max]	8.5 A
Efficiency	90 %
Mounting Type	Chassis Mount
Number of Outputs	1
Operating Temperature [Max]	75 ░C
Operating Temperature [Min]	-40 °C
Power (Watts)	238 W
Size / Dimension [x]	3.35 in
Size / Dimension [x]	85.1 mm
Size / Dimension [y]	2.4 "
Size / Dimension [y]	61 mm
Size / Dimension [z]	1.53 in
Size / Dimension [z]	38.9 mm
Type	Open Frame
Voltage - Input (Max) [Max]	160 V
Voltage - Input (Min) [Min]	43 V
Voltage - Isolation	3000 V
Voltage - Output 1	28 V

TEP 200 Series

Part	Operating Temperature [Min]	Operating Temperature [Max]	Approval Agency	Voltage - Input (Max) [Max]	Mounting Type	Efficiency	Power (Watts)	Voltage - Output 1	Number of Outputs	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Applications	Type	Voltage - Isolation	Current - Output (Max) [Max]	Voltage - Input (Min) [Min]	Package / Case	Supplier Device Package	Features
Traco Power TEP 200-7216WIRCMF	-40 °C	75 ░C	CB CE cURus	160 V	Chassis Mount	90 %	238 W	28 V	1	1.53 in	38.9 mm	3.35 in	2.4 "	85.1 mm	61 mm	ITE (Commercial) Railway	Open Frame	3000 V	8.5 A	43 V
Traco Power TEP 200-2411WIRCM	-40 °C	75 ░C	CB CE cURus	36 V	Chassis Mount	90 %	180 W	5 V	1		1.33 " 33.8 mm			3.35 " 85.1 mm	2.4 " 61 mm	ITE (Commercial) Railway	Enclosed	3000 V	36 A	9 V
Traco Power TEP 200-2413WIR	-40 °C	75 ░C		36 V	Through Hole	90 %	180 W	15 V	1	0.5 in	12.7 mm	2.4 in	2.28 in	61 mm	57.9 mm	ITE (Commercial) Railway	Isolated Module	2250 VDC	12 A	9 V	Half Brick	Half Brick	OTP OVP Remote On/Off SCP UVLO
Traco Power TEP 200-4813WIR	-40 °C	75 ░C		75 V	Through Hole	91 %	210 W	15 V	1	0.5 in	12.7 mm	2.4 in	2.28 in	61 mm	57.9 mm	ITE (Commercial) Railway	Isolated Module	2250 VDC	14 A	18 V	Half Brick	Half Brick	OTP OVP Remote On/Off SCP UVLO
Traco Power TEP 200-4818WIR	-40 °C	75 ░C		75 V	Through Hole	90 %	216 W	48 V	1	0.5 in	12.7 mm	2.4 in	2.28 in	61 mm	57.9 mm	ITE (Commercial) Railway	Isolated Module	2250 VDC	4.5 A	18 V	Half Brick	Half Brick	OTP OVP Remote On/Off SCP UVLO
Traco Power TEP 200-4816WIRCM	-40 °C	75 ░C	CB CE cURus	75 V	Chassis Mount	91 %	210 W	28 V	1		1.33 " 33.8 mm			3.35 " 85.1 mm	2.4 " 61 mm	ITE (Commercial) Railway	Enclosed	3000 V	7.5 A	18 V
Traco Power TEP 200-4816WIRCMF	-40 °C	75 ░C	CB CE cURus	75 V	Chassis Mount	91 %	210 W	28 V	1	1.53 in	38.9 mm	3.35 in	2.4 "	85.1 mm	61 mm	ITE (Commercial) Railway	Open Frame	3000 V	7.5 A	18 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 481.70

Description

General part information

TEP 200 Series

Open Frame DC DC Converter 1 Output 28V 8.5A 160V Input
