9TG24P0G01
ActiveSanyo Denki America Inc.
FAN IMP MTRZD 175X69MM 24VDC
Deep-Dive with AI
Search across all available documentation for this part.
9TG24P0G01
ActiveSanyo Denki America Inc.
FAN IMP MTRZD 175X69MM 24VDC
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 9TG24P0G01 |
|---|---|
| Air Flow | 494.7 CFM |
| Air Flow | 13.85 m³/min |
| Approval Agency | CSA, TUV, UL |
| Bearing Type | Ball |
| Current Rating (Amps) | 3.9 A |
| Fan Type | Motorized Impellers |
| Features | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) |
| Lifetime @ Temp. | 40000 Hrs |
| Material - Blade | Plastic |
| Material - Frame | Aluminum |
| Noise | 73 dB(A) |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -20 °C |
| Operating Temperature [Min] | -20 C |
| Power (Watts) | 93.6 W |
| Size / Dimension [diameter] | 175 mm Dia |
| Static Pressure | 3.55 in H2O |
| Static Pressure | 885 Pa |
| Termination | 4 Wire Leads |
| Voltage - Rated | 24 VDC |
| Weight | 771.1 g |
| Weight | 1.7 lbs |
| Width [x] | 69 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 137.62 | |
| 10 | $ 127.50 | |||
Description
General part information
9TG24 Series
Fan Motorized Impellers 24VDC Round - 175mm Dia Ball 494.7 CFM (13.85m³/min) 4 Wire Leads
