VOF-550-30

Active

CUI Inc.

AC/DC CONVERTER 30V 150W

Search across all available documentation for this part.

Active

CUI Inc.

AC/DC CONVERTER 30V 150W

Technical Specifications

Parameters and characteristics for this part

Specification	VOF-550-30

Applications	ITE (Commercial)
Approval Agency	SIQ, CB Scheme, EN, UL, TUV, IEC, FCC
Current - Output 1	5 A
Efficiency	91 %
Features	Universal Input, Adjustable Output, PFC, Standby Output
Mounting Type	Chassis Mount
Number of Outputs	1
Power (Watts)	550 W
Power (Watts)	150 W
Size / Dimension [x]	5 in
Size / Dimension [x]	127 mm
Size / Dimension [y]	3 "
Size / Dimension [y]	76.2 mm
Size / Dimension [z]	38.1 mm
Size / Dimension [z]	1.5 "
Standard Number	55024, 55032 Class B, 61000-3-3, 61000-3-2, 60950-1
Type	Open Frame
Voltage - Input [Max]	264 VAC
Voltage - Input [Min]	90 VAC
Voltage - Isolation	3000 V
Voltage - Output 1	30 V

Part	Number of Outputs	Power (Watts)	Power (Watts)	Mounting Type	Standard Number	Features	Voltage - Isolation	Voltage - Input [Min]	Voltage - Input [Max]	Applications	Current - Output 1	Type	Efficiency	Voltage - Output 1	Approval Agency	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]
CUI Inc. VOF-550-24	1	550 W	150 W	Chassis Mount	55024 55032 Class B 60950-1 61000-3-2 61000-3-3	Adjustable Output Standby Output Universal Input	3000 V	90 VAC	264 VAC	ITE (Commercial)	6.25 A	Open Frame	91 %	24 V	CB Scheme EN FCC IEC SIQ TUV UL	5 in	3 "	127 mm	38.1 mm	76.2 mm	1.5 "
CUI Inc. VOF-550-12	1	500 W	120 W	Chassis Mount	55024 55032 Class B 60950-1 61000-3-2 61000-3-3	Adjustable Output Standby Output Universal Input	3000 V	90 VAC	264 VAC	ITE (Commercial)	10 A	Open Frame	90 %	12 V	CB Scheme EN FCC IEC SIQ TUV UL	5 in	3 "	127 mm	38.1 mm	76.2 mm	1.5 "
CUI Inc. VOF-550-30	1	550 W	150 W	Chassis Mount	55024 55032 Class B 60950-1 61000-3-2 61000-3-3	Adjustable Output PFC Standby Output Universal Input	3000 V	90 VAC	264 VAC	ITE (Commercial)	5 A	Open Frame	91 %	30 V	CB Scheme EN FCC IEC SIQ TUV UL	5 in	3 "	127 mm	38.1 mm	76.2 mm	1.5 "

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	84	$ 225.89

General part information

Open Frame AC DC Converters 1 Output 30V 90 ~ 264 VAC Input
