VS-36MB40A

Active

Vishay General Semiconductor - Diodes Division

BRIDGE RECT 1PHASE 400V 35A D-34

Search across all available documentation for this part.

Active

Vishay General Semiconductor - Diodes Division

BRIDGE RECT 1PHASE 400V 35A D-34

Technical Specifications

Parameters and characteristics for this part

Specification	VS-36MB40A

Current - Average Rectified (Io)	35 A
Current - Reverse Leakage @ Vr	10 µA
Diode Type	Single Phase
Mounting Type	QC Terminal
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-55 °C
Package / Case	4-Square, D-34
Supplier Device Package	D-34
Technology	Standard
Voltage - Peak Reverse (Max) [Max]	400 V

Part	Current - Average Rectified (Io)	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Technology	Voltage - Peak Reverse (Max) [Max]	Current - Reverse Leakage @ Vr	Supplier Device Package	Mounting Type	Diode Type
Vishay General Semiconductor - Diodes Division VS-36MB40A	35 A	4-Square D-34	-55 °C	150 °C	Standard	400 V	10 µA	D-34	QC Terminal	Single Phase
