PDRB-30-5

CUI Inc.

AC/DC DIN RAIL SUPPLY 5V 15W

Search across all available documentation for this part.

CUI Inc.

AC/DC DIN RAIL SUPPLY 5V 15W

Technical Specifications

Parameters and characteristics for this part

Specification	PDRB-30-5

AC Voltage - Input [Max]	264 VAC
AC Voltage - Input [Min]	85 VAC
Applications	ITE (Commercial)
Approval Agency	CE, cURus
Current - Output (Max) [Max]	3 A
DC Voltage - Input (Max) [Max]	370 V
DC Voltage - Input (Min) [Min]	120 V
Features	Adjustable Output, Universal Input
Input Type	AC or DC
Number of Outputs	1
Power (Watts)	15 W
Size / Dimension [x]	58 mm
Size / Dimension [x]	2.28 in
Size / Dimension [y]	1.38 "
Size / Dimension [y]	35 mm
Size / Dimension [z]	92.7 mm
Size / Dimension [z]	3.65 in
Standard Number	62368-1
Voltage - Isolation	4000 V
Voltage - Output 1	5 V

Part	Input Type	DC Voltage - Input (Max) [Max]	Standard Number	DC Voltage - Input (Min) [Min]	Applications	Current - Output (Max) [Max]	Power (Watts)	AC Voltage - Input [Min]	AC Voltage - Input [Max]	Efficiency	Voltage - Isolation	Features	Number of Outputs	Voltage - Output 1	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Approval Agency
CUI Inc. PDRB-30-48	AC or DC	370 V	62368-1	120 V	ITE (Commercial)	750 mA	36 W	85 VAC	264 VAC	90 %	4000 V	Adjustable Output Universal Input	1	48 V	1.38 "	92.7 mm	58 mm	35 mm	3.65 in	2.28 in	CE cURus
CUI Inc. PDRB-30-5	AC or DC	370 V	62368-1	120 V	ITE (Commercial)	3 A	15 W	85 VAC	264 VAC		4000 V	Adjustable Output Universal Input	1	5 V	1.38 "	92.7 mm	58 mm	35 mm	3.65 in	2.28 in	CE cURus

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

AC/DC DIN RAIL SUPPLY 5V 15W

Technical documentation and resources

No documents available
