BK10C05-30DP/2-0.3V(800)

Active

Hirose Electric USA, Inc.

CONN HDR 0.3MM SMD 30POS+2PWR

Search across all available documentation for this part.

Active

Hirose Electric USA, Inc.

CONN HDR 0.3MM SMD 30POS+2PWR

Technical Specifications

Parameters and characteristics for this part

Specification	BK10C05-30DP/2-0.3V(800)

Connector Type	Header, Outer Shroud Contacts
Contact Finish	Gold
Contact Finish Thickness	1.97 Áin
Contact Finish Thickness	0.05 Ám
Features	Solder Retention
Height Above Board	0.41 mm
Height Above Board [z]	0.016 "
Mated Stacking Heights	0.5 mm
Mounting Type	Surface Mount
Number of Positions [custom]	30
Number of Positions [custom]	2
Number of Rows	2
Pitch [x]	0.012 in
Pitch [x]	0.3 mm

Part	Height Above Board [z]	Height Above Board	Number of Positions [custom]	Number of Positions [custom]	Connector Type	Number of Rows	Mounting Type	Contact Finish	Mated Stacking Heights	Pitch [x]	Pitch [x]	Contact Finish Thickness	Contact Finish Thickness	Features
Hirose Electric USA, Inc. BK10C05-30DP/2-0.3V(800)	0.016 "	0.41 mm	30	2	Header Outer Shroud Contacts	2	Surface Mount	Gold	0.5 mm	0.012 in	0.3 mm	1.97 Áin	0.05 Ám	Solder Retention

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	20000	$ 0.57

General part information

32 (30 + 2 Power) Position Connector Header, Outer Shroud Contacts Surface Mount Gold
