MU425S48EC

Active

SL POWER / Advanced Energy

AC/DC CONVERTER 48V 283W

Search across all available documentation for this part.

Active

SL POWER / Advanced Energy

AC/DC CONVERTER 48V 283W

Technical Specifications

Parameters and characteristics for this part

Specification	MU425S48EC

Applications	Medical
Approval Agency	CE
Efficiency	88 %
Features	PFC, Standby Output, Universal Input, Remote Sense, Adjustable Output
Minimum Load Required	False
Mounting Type	Chassis Mount
Number of Outputs	1
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-10 °C
Power (Watts)	403 W
Power (Watts)	283 W
Size / Dimension [x]	157.5 mm
Size / Dimension [x]	6.2 in
Size / Dimension [y]	3.3 in
Size / Dimension [y]	83.8 mm
Size / Dimension [z]	1.62 in
Size / Dimension [z]	41.1 mm
Standard Number	60601-1
Type	Enclosed
Voltage - Input [Max]	300 VDC, 264 VAC
Voltage - Input [Min]	120 VDC, 90 VAC
Voltage - Isolation	1.5 kV
Voltage - Output 1	48 V

Part	Power (Watts)	Power (Watts)	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Isolation	Number of Outputs	Minimum Load Required	Type	Efficiency	Voltage - Output 1	Voltage - Input [Min]	Voltage - Input [Max]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Approval Agency	Mounting Type	Features	Applications	Standard Number
SL POWER / Advanced Energy MU425S48EC	403 W	283 W	-10 °C	70 °C	1.5 kV	1		Enclosed	88 %	48 V	90 VAC 120 VDC	264 VAC 300 VDC	157.5 mm	6.2 in	3.3 in	83.8 mm	1.62 in	41.1 mm	CE	Chassis Mount	Adjustable Output PFC Remote Sense Standby Output Universal Input	Medical	60601-1

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Enclosed AC DC Converters 1 Output 48V 90 ~ 264 VAC, 120 ~ 300 VDC Input
