PE42451MLIAA-Z
ActivepSemi Corporation
IC RF SWITCH SP5T 4GHZ 24QFN
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PE42451MLIAA-Z
ActivepSemi Corporation
IC RF SWITCH SP5T 4GHZ 24QFN
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PE42451MLIAA-Z |
|---|---|
| Circuit | SP5T |
| Features | DC Blocked |
| Frequency Range [Max] | 4 GHz |
| Frequency Range [Min] | 450 MHz |
| IIP3 | 58 dBm |
| Impedance | 50 Ohms |
| Insertion Loss | 2.25 dB |
| Isolation | 50 dB |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| P1dB | 35 dBm |
| Package / Case | 24-WFQFN Exposed Pad |
| RF Type | General Purpose |
| Supplier Device Package | 24-QFN (4x4) |
| Test Frequency | 4 GHz |
| Topology | Absorptive |
| Voltage - Supply [Max] | 3.3 V |
| Voltage - Supply [Min] | 2.7 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 3000 | $ 3.73 | |
Description
General part information
PE42451 Series
RF Switch IC General Purpose SP5T 4 GHz 50Ohm 24-QFN (4x4)
