LZC-00UB00-00U4

Active

ams-OSRAM USA INC.

LED EMITTER UV VIOLET SMD

Search across all available documentation for this part.

Active

ams-OSRAM USA INC.

LED EMITTER UV VIOLET SMD

Technical Specifications

Parameters and characteristics for this part

Part	Orientation	Package / Case	Mounting Type	Voltage - Forward (Vf) (Typ)	Current - DC Forward (If) (Max)	Type	Wavelength [Min]	Wavelength [Max]	Viewing Angle	Operating Temperature	Wavelength	Current - Max [Max]	CCT (K)	Color	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	CRI (Color Rendering Index)	Supplier Device Package	Lumens/Watt @ Current - Test	Flux @ 25°C, Current - Test	Flux @ 25°C, Current - Test [Max]	Flux @ 25°C, Current - Test [Min]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Thermal Resistance of Package [custom]
ams-OSRAM USA INC. LZC-00UB00-00U5	Top View	24-SMD No Lead Exposed Pad	Surface Mount	44 V	1 A	Ultraviolet (UV)	390 nm	395 nm	115 °	130 °C
ams-OSRAM USA INC. LZC-00UB00-00U4	Top View	24-SMD No Lead Exposed Pad	Surface Mount	44 V	1 A	Ultraviolet (UV)	385 nm	390 nm	115 °	130 °C	388 nm
ams-OSRAM USA INC. LZC-00CW0R-0055		24-SMD No Lead Exposed Pad	Surface Mount						110 °			1.2 A	5500 K	Cool White	0.22 in	5.6 mm	70	SMD	76 lm/W	2014 lm	2120 lm	1908 lm	9 mm	9 mm	0.354 "	0.354 in	0.7 °C/W

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Ultraviolet (UV) Emitter 388nm (385nm ~ 390nm) 44V 1A 115° 24-SMD, No Lead Exposed Pad

Technical documentation and resources
