TS12-74-60-BK-250-SMT-TR
ActiveCUI Devices
SWITCH TACTILE SPST-NO 0.05A 12V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TS12-74-60-BK-250-SMT-TR
ActiveCUI Devices
SWITCH TACTILE SPST-NO 0.05A 12V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | TS12-74-60-BK-250-SMT-TR |
|---|---|
| Actuator Height off PCB, Vertical [z] | 6 mm |
| Actuator Material | Polyphthalamide (PPA) |
| Actuator Orientation | Top Actuated |
| Actuator Type | Plunger for Cap |
| Circuit | SPST-NO |
| Contact Rating @ Voltage | 0.05 A, 12 VDC |
| Illumination | Non-Illuminated |
| Mounting Type | Surface Mount |
| Operating Force | 0.25 kgf |
| Operating Temperature [Max] | 80 C |
| Operating Temperature [Min] | -30 ░C |
| Outline [x] | 7.4 mm |
| Outline [y] | 7.4 mm |
| Switch Function | Off-Mom |
| Switch Travel | 0.25 mm |
| Termination Style | J Lead |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 1.07 | |
| 10 | $ 1.03 | |||
| 25 | $ 0.96 | |||
| 100 | $ 0.83 | |||
| 250 | $ 0.76 | |||
| Digi-Reel® | 1 | $ 1.07 | ||
| 10 | $ 1.03 | |||
| 25 | $ 0.96 | |||
| 100 | $ 0.83 | |||
| 250 | $ 0.76 | |||
| Tape & Reel (TR) | 800 | $ 0.49 | ||
Description
General part information
TS12-74 Series
Tactile Switch SPST-NO Top Actuated Surface Mount
