VX7815-500

CUI Inc.

DC DC CONVERTER 15V 7.5W

Search across all available documentation for this part.

CUI Inc.

DC DC CONVERTER 15V 7.5W

Technical Specifications

Parameters and characteristics for this part

Specification	VX7815-500

Applications	ITE (Commercial)
Approval Agency	EN, CB Scheme, UL, IEC
Current - Output (Max) [Max]	500 mA
Efficiency	95 %
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	3-SIP Module
Power (Watts)	7.5 W
Size / Dimension [x]	0.46 in
Size / Dimension [x]	11.6 mm
Size / Dimension [y]	7.6 mm
Size / Dimension [y]	0.3 "
Size / Dimension [z]	10.2 mm
Size / Dimension [z]	0.4 "
Standard Number	55024, 60950-1, 55032 Class A
Type	Linear Regulator Replacement
Voltage - Input (Max) [Max]	36 V
Voltage - Input (Min) [Min]	19 V
Voltage - Output 1	15 V

Part	Power (Watts)	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Voltage - Output 1	Number of Outputs	Voltage - Input (Max) [Max]	Current - Output (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Input (Min) [Min]	Standard Number	Applications	Efficiency	Type	Package / Case	Approval Agency	Mounting Type
CUI Inc. VX7815-500	7.5 W	7.6 mm	0.46 in	11.6 mm	10.2 mm	0.4 "	0.3 "	15 V	1	36 V	500 mA	85 °C	-40 °C	19 V	55024 55032 Class A 60950-1	ITE (Commercial)	95 %	Linear Regulator Replacement	3-SIP Module	CB Scheme EN IEC UL	Through Hole

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	43	$ 2.57

General part information

Linear Regulator Replacement DC DC Converter 1 Output 15V 500mA 19V - 36V Input
