4656ZW

Active

ebm-papst Inc.

FAN AXIAL 119X38MM 230VAC WIRE

Search across all available documentation for this part.

Active

ebm-papst Inc.

FAN AXIAL 119X38MM 230VAC WIRE

Technical Specifications

Parameters and characteristics for this part

Part	Size / Dimension [y]	Size / Dimension [x]	Material - Blade	Noise	RPM	Voltage - Rated	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Material - Frame	Fan Type	Lifetime @ Temp.	Power (Watts)	Width [y]	Termination	Bearing Type	Ingress Protection	Approval Agency	Air Flow	Air Flow	Weight	Weight	Size / Dimension [diameter]
ebm-papst Inc. 4656ZH	119 mm	119 mm	Steel	40 dB(A)	2650 RPM	230 VAC	75 °C	-40 °C	75 ░C	-40 °C	Aluminum	Tubeaxial	40 °C 37500 Hrs	19 W	38 mm	2 Terminals	Ball	IP54 IP65
ebm-papst Inc. 4656Z	119 mm	119 mm	Metal	40 dB(A)	2650 RPM	230 VAC	75 °C	-40 °C	75 ░C	-40 °C	Metal	Tubeaxial	40 °C 37500 Hrs	19 W	38 mm	2 Terminals	Ball		CE CSA UL VDE
ebm-papst Inc. 4656X	119 mm	119 mm	Metal	51 dB(A)		230 VAC					Metal	Tubeaxial		18 W	38 mm	2 Terminals	Ball		CSA UL VDE	106 CFM	2.97 mł/min
ebm-papst Inc. 4656TZ			Metal	42 dB	2600 RPM	230 VAC	65 °C	-40 °C	65 °C	-40 °C	Metal	Tubeaxial	40 °C 37500 Hrs	19 W	37 mm	2 Wire Leads	Ball		CE CSA UL VDE	73.6 CFM	2.06 m³/min	0.956 lb	433.63 g	108 mm
ebm-papst Inc. 4656ZWU	119 mm	119 mm	Metal	42 dB	3100 RPM	230 VAC	80 °C	-40 °C	80 C	-40 °C	Metal	Tubeaxial	40 °C 37500 Hrs	17 W	38 mm	2 Wire Leads	Ball	IP65 - Dust Tight Water Resistant	CCC CE CSA UL VDE	105.9 CFM	2.97 mł/min
ebm-papst Inc. 4656ZW	119 mm	119 mm	Metal	40 dB(A)	2650 RPM	230 VAC	75 °C	-40 °C	75 ░C	-40 °C	Metal	Tubeaxial	40 °C 37500 Hrs	19 W	38 mm	2 Wire Leads	Ball			94.2 CFM	2.64 mł/min

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	50	$ 47.72

General part information

Fan Tubeaxial 230VAC Square - 119mm L x 119mm H Ball 94.2 CFM (2.64mł/min) 2 Wire Leads
