D38999/26MF32JB

Active

Souriau-Sunbank by Eaton

D38999/26MF32JB

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

D38999/26MF32JB

Active

Souriau-Sunbank by Eaton

D38999/26MF32JB

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	D38999/26MF32JB

Applications	Aviation, Marine, Military, Aerospace
Connector Type	Female Sockets, Plug
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	2.54 çm
Contact Finish Thickness - Mating	100 çin
Contact Material	Copper Alloy
Current Rating (Amps)	7.5 A
Features	Coupling Nut
Grade	Military
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Thermoplastic
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Operating Temperature [Max]	200 °C
Operating Temperature [Min]	-65 ░C
Orientation	B
Primary Material	Composite
Qualification	MIL-DTL-38999 Series II, MIL-DTL-38999 Series III
Shell Finish	Nickel
Shell Material	Composite
Shell Size - Insert [Max]	32
Shell Size - Insert [Min]	19
Shell Size, MIL	F
Shielding	Shielded
Termination	Crimp
Voltage Rating	500 VAC

D38999/26MF Series

Part	Type	Note	Qualification	Contact Size	Features	Shell Size - Insert [Min]	Shell Size - Insert [Max]	Ingress Protection	Contact Shape	Mounting Type	Orientation	Grade	Shell Material	Shielding	Shell Size, MIL	Housing Color	Insert Material	Contact Type	Connector Type	Operating Temperature [Min]	Operating Temperature [Max]	Shell Finish	Contact Finish - Mating	Primary Material	Applications	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Current Rating (Amps)	Contact Material	Termination	Voltage Rating	Material Flammability Rating
Souriau-Sunbank by Eaton D38999/26MF32SAL
Souriau-Sunbank by Eaton D38999/26MF32BB	For Female Sockets	Contacts Not Included	MIL-DTL-38999 Series III	20	Coupling Nut	19	32	Environment Resistant	Circular	Free Hanging (In-Line)	B	Military	Composite	Shielded	F	Silver	Plastic	Crimp	Plug Housing	-65 ░C	200 °C	Electroless Nickel
Souriau-Sunbank by Eaton D38999/26MF32SA			MIL-DTL-38999 Series III		Coupling Nut	19	32	IP67 - Dust Tight Waterproof		Free Hanging (In-Line)	A	Military	Composite	Shielded	F		Thermoplastic		Female Sockets Plug	-65 ░C	200 °C	Nickel	Gold	Composite	Aviation Marine Military	1.27 µm	50 µin	7.5 A	Copper Alloy	Crimp
Souriau-Sunbank by Eaton D38999/26MF32BA	For Female Sockets	Contacts Not Included	MIL-DTL-38999 Series III	20	Coupling Nut	19	32	Environment Resistant	Circular	Free Hanging (In-Line)	A	Military	Composite	Shielded	F	Silver	Plastic	Crimp	Plug Housing	-65 ░C	200 °C	Electroless Nickel
Souriau-Sunbank by Eaton D38999/26MF32JN			MIL-DTL-38999 Series III		Coupling Nut	19	32	IP67 - Dust Tight Waterproof		Free Hanging (In-Line)	N	Military	Composite	Shielded	F		Thermoplastic		Female Sockets Plug	-65 ░C	200 °C	Nickel	Gold	Composite	Aviation Marine Military	2.54 çm	100 çin	7.5 A	Copper Alloy	Crimp
Souriau-Sunbank by Eaton D38999/26MF32JA			MIL-DTL-38999 Series III		Coupling Nut	19	32	IP67 - Dust Tight Waterproof		Free Hanging (In-Line)	A	Military	Composite	Shielded	F		Thermoplastic		Female Sockets Plug	-65 ░C	200 °C	Nickel	Gold	Composite	Aviation Marine Military	2.54 çm	100 çin	7.5 A	Copper Alloy	Crimp
Souriau-Sunbank by Eaton D38999/26MF32JB			MIL-DTL-38999 Series II MIL-DTL-38999 Series III		Coupling Nut	19	32	IP67 - Dust Tight Waterproof		Free Hanging (In-Line)	B	Military	Composite	Shielded	F		Thermoplastic		Female Sockets Plug	-65 ░C	200 °C	Nickel	Gold	Composite	Aerospace Aviation Marine Military	2.54 çm	100 çin	7.5 A	Copper Alloy	Crimp	500 VAC	UL94 V-0

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 129.30
		25	$ 119.73
		250	$ 96.50
		1000	$ 88.57
	Box	5	$ 214.34
		10	$ 197.20
		50	$ 181.42
		100	$ 166.91
		500	$ 153.55

Description

General part information

D38999/26MF Series

32 Position Circular Connector Plug, Female Sockets Crimp
