PUA0312S1A
ActiveFlex Power Modules
DC DC CONVERTER 12V 1W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PUA0312S1A |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | IEC, cURus, UL |
| Current - Output (Max) [Max] | 84 mA |
| Efficiency | 77 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 4-SIP Module |
| Size / Dimension [x] | 11.6 mm |
| Size / Dimension [x] | 0.46 in |
| Size / Dimension [y] | 6 mm |
| Size / Dimension [y] | 0.24 " |
| Size / Dimension [z] | 0.4 " |
| Size / Dimension [z] | 10.2 mm |
| Standard Number | 62368-1 |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 3.63 V |
| Voltage - Input (Min) [Min] | 2.97 V |
| Voltage - Isolation | 2000 V |
| Voltage - Output 1 | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 41 | $ 3.10 | |
Description
General part information
PUA0312 Series
Isolated Module DC DC Converter 1 Output 12V 84mA 2.97V - 3.63V Input
