LKP5660-9ERG

Active

EOS Power India Private Ltd

AC/DC CONVERTER 24V 24V 280W

Search across all available documentation for this part.

Active

EOS Power India Private Ltd

AC/DC CONVERTER 24V 24V 280W

Technical Specifications

Parameters and characteristics for this part

Specification	LKP5660-9ERG

Applications	Railway, ITE (Commercial)
Approval Agency	cCSAus, CE, NEMKO
Current - Output 1	5.2 A
Current - Output 2	5.2 A
Efficiency	87 %
Features	Load Sharing, PFC, Remote On/Off, Adjustable Output, Universal Input
Mounting Type	Chassis Mount
Number of Outputs	2
Operating Temperature [Max]	71 °C
Operating Temperature [Min]	-40 °C
Power (Watts)	280 W
Size / Dimension [x]	168 mm
Size / Dimension [x]	6.6 "
Size / Dimension [y]	111 mm
Size / Dimension [y]	4.4 "
Size / Dimension [z]	3.2 in
Size / Dimension [z]	80 mm
Type	Conformal Coated, Enclosed
Voltage - Input [Max]	255 VAC
Voltage - Input [Min]	187 VAC
Voltage - Isolation	2.8 kV
Voltage - Output 1	24 V
Voltage - Output 2	24 V

Part	Voltage - Isolation	Type	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Current - Output 2	Number of Outputs	Efficiency	Power (Watts)	Voltage - Output 2	Applications	Voltage - Output 1	Current - Output 1	Features	Voltage - Input [Min]	Voltage - Input [Max]	Approval Agency
EOS Power India Private Ltd LKP5660-7R	4000 V	Conformal Coated Enclosed	Chassis Mount	-25 °C	71 °C	168 mm	111 mm	3.2 in	80 mm	6.6 "	4.4 "	5.2 A	2	86 %	280 W	24 V	ITE (Commercial) Railway	24 V	5.2 A	Load Sharing PFC Universal Input
EOS Power India Private Ltd LKP5660-9ER	4000 V	Conformal Coated Enclosed	Chassis Mount	-40 °C	71 °C	168 mm	111 mm	3.2 in	80 mm	6.6 "	4.4 "	5.2 A	2	86 %	250 W	24 V	ITE (Commercial) Railway	24 V	5.2 A	Adjustable Output DC Input Capable Remote On/Off Remote Sense Universal Input
EOS Power India Private Ltd LKP5660-9ERG	2.8 kV	Conformal Coated Enclosed	Chassis Mount	-40 °C	71 °C	168 mm	111 mm	3.2 in	80 mm	6.6 "	4.4 "	5.2 A	2	87 %	280 W	24 V	ITE (Commercial) Railway	24 V	5.2 A	Adjustable Output Load Sharing PFC Remote On/Off Universal Input	187 VAC	255 VAC	cCSAus CE NEMKO

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Enclosed, Conformal Coated AC DC Converters 2 Output 24V 24V 187 ~ 255 VAC Input
