ASMT-AA30-ARS00

Obsolete

Broadcom Limited

LED AMBER 590NM 2SMD

Search across all available documentation for this part.

Obsolete

Broadcom Limited

LED AMBER 590NM 2SMD

Technical Specifications

Parameters and characteristics for this part

Specification	ASMT-AA30-ARS00

Color	Amber
Current - Max [Max]	700 mA
Current - Test	350 mA
Height - Seated (Max)	4.2 mm
Height - Seated (Max) [Max]	0.165 in
Lumens/Watt @ Current - Test	73 lm/W
Luminous Flux @ Current/Temperature	54 lm
Mounting Type	Surface Mount
Package / Case	2-SMD, Gull Wing Exposed Pad
Size / Dimension [diameter]	0.315 "
Size / Dimension [diameter]	8 mm
Supplier Device Package	2-SMD
Thermal Resistance of Package [diameter]	10 °C/W
Viewing Angle	140 °
Voltage - Forward (Vf) (Typ)	2.1 V
Wavelength	590 nm
Wavelength [Max]	597 nm
Wavelength [Min]	587 nm

Part	Package / Case	Size / Dimension [diameter]	Size / Dimension [diameter]	Supplier Device Package	Lumens/Watt @ Current - Test	Mounting Type	Viewing Angle	Voltage - Forward (Vf) (Typ)	Luminous Flux @ Current/Temperature	Thermal Resistance of Package [diameter]	Height - Seated (Max) [Max]	Height - Seated (Max)	Wavelength [Max]	Wavelength	Wavelength [Min]	Current - Test	Current - Max [Max]	Color
Broadcom Limited ASMT-AA30-ARS00	2-SMD Gull Wing Exposed Pad	0.315 "	8 mm	2-SMD	73 lm/W	Surface Mount	140 °	2.1 V	54 lm	10 °C/W	0.165 in	4.2 mm	597 nm	590 nm	587 nm	350 mA	700 mA	Amber

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

LED Lighting Color - Amber 590nm (587nm ~ 597nm) 2-SMD, Gull Wing Exposed Pad
