XZVG53S-4

Active

SunLED

LED GREEN CLEAR 0603 SMD

Search across all available documentation for this part.

Active

SunLED

LED GREEN CLEAR 0603 SMD

Technical Specifications

Parameters and characteristics for this part

Part	Lens Style	Configuration	Lens Size [diameter]	Lens Color	Size / Dimension [x]	Size / Dimension [y]	Current - Test	Package / Case	Mounting Type	Voltage - Forward (Vf) (Typ)	Lens Transparency	Viewing Angle	Wavelength - Dominant	Color	Millicandela Rating	Height (Max) [Max] [z]	Supplier Device Package	Lens Size [x]	Lens Size [y]
SunLED XZVG53W-8ST	Round with Domed Top	Standard	0.7 mm	Colorless	1.6 mm	0.8 mm	20 mA	0603 (1608 Metric)	Surface Mount	2.1 V	Clear	100 °	570 nm	Green	79 mcd	0.8 mm	Chip LED
SunLED XZVG53S-4	Rectangle with Flat Top			Colorless	1.6 mm	0.8 mm	20 mA	0603 (1608 Metric)	Surface Mount	2.1 V	Clear	120 °	570 nm	Green	74 mcd	0.7 mm		1.4 mm	0.8 mm
SunLED XZVG53W-3	Rectangle with Flat Top	Standard		Colorless	1.6 mm	0.8 mm	20 mA	0603 (1608 Metric)	Surface Mount	2.1 V	Clear	120 °	570 nm	Green	49 mcd	0.45 mm	Chip LED	1.1 mm	0.8 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Green 570nm LED Indication - Discrete 2.1V 0603 (1608 Metric)
