3533001N010

Active

APEM

SWITCH TOGGLE SPST 15A 28V

Search across all available documentation for this part.

Active

APEM

SWITCH TOGGLE SPST 15A 28V

Technical Specifications

Parameters and characteristics for this part

Specification	3533001N010

Actuator Length [x]	17.5 mm
Actuator Material	Brass, Nickel Plated
Actuator Type	Standard Round
Bushing Thread	15/32-32
Circuit	SPST
Current Rating (Amps)	15 A
Electrical Life	10000 Cycles
Illumination	Non-Illuminated
Ingress Protection	IP67 - Dust Tight, Waterproof
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Panel Cutout Dimensions [diameter]	12.2 mm
Switch Function	Off-Mom
Termination Style	Screw Terminal
Voltage Rating - DC	28 V

Part	Switch Function	Panel Cutout Dimensions [diameter]	Actuator Material	Actuator Type	Bushing Thread	Current Rating (Amps)	Actuator Length [x]	Termination Style	Voltage Rating - DC	Illumination	Operating Temperature [Max]	Operating Temperature [Min]	Circuit	Electrical Life	Ingress Protection
APEM 3533001N010	Off-Mom	12.2 mm	Brass Nickel Plated	Standard Round	15/32-32	15 A	17.5 mm	Screw Terminal	28 V	Non-Illuminated	85 °C	-40 °C	SPST	10000 Cycles	IP67 - Dust Tight Waterproof

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	25	$ 59.17

General part information

Toggle Switch SPST Panel Mount
