TSR 2-0515

Active

Traco Power

DC DC CONVERTER 1.5V 3W

Search across all available documentation for this part.

Active

Traco Power

DC DC CONVERTER 1.5V 3W

Technical Specifications

Parameters and characteristics for this part

Specification	TSR 2-0515

Applications	ITE (Commercial)
Current - Output (Max) [Max]	2 A
Efficiency	91 %
Features	OCP, SCP
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	3-SIP Module
Power (Watts)	3 W
Size / Dimension [x]	14 mm
Size / Dimension [x]	0.55 in
Size / Dimension [y]	0.3 "
Size / Dimension [y]	7.5 mm
Size / Dimension [z]	10.1 mm
Size / Dimension [z]	0.4 "
Type	Linear Regulator Replacement
Voltage - Input (Max) [Max]	5.5 V
Voltage - Input (Min) [Min]	3 V
Voltage - Output 1	1.5 V

Part	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Current - Output (Max) [Max]	Applications	Voltage - Input (Max) [Max]	Type	Voltage - Input (Min) [Min]	Package / Case	Number of Outputs	Voltage - Output 1	Operating Temperature [Max]	Operating Temperature [Min]	Efficiency	Mounting Type	Features	Power (Watts)
Traco Power TSR 2-0518	14 mm	0.3 "	10.1 mm	0.55 in	0.4 "	7.5 mm	2 A	ITE (Commercial)	5.5 V	Linear Regulator Replacement	3 V	3-SIP Module	1	1.8 V	85 °C	-40 °C	92 %	Through Hole	OCP SCP	3.6 W
Traco Power TSR 2-24150	14 mm	0.3 "	10.1 mm	0.55 in	0.4 "	7.5 mm	2 A	ITE (Commercial)	36 V	Linear Regulator Replacement	18 V	3-SIP Module	1	15 V	85 °C	-40 °C	96 %	Through Hole	OCP SCP	30 W
Traco Power TSR 2-0515	14 mm	0.3 "	10.1 mm	0.55 in	0.4 "	7.5 mm	2 A	ITE (Commercial)	5.5 V	Linear Regulator Replacement	3 V	3-SIP Module	1	1.5 V	85 °C	-40 °C	91 %	Through Hole	OCP SCP	3 W

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Linear Regulator Replacement DC DC Converter 1 Output 1.5V 2A 3V - 5.5V Input
