EXSAM1B256GB0M1I00

Active

ExAscend

SSD 256GB MSATA MLC SATAIII 3.3V

Search across all available documentation for this part.

Active

ExAscend

SSD 256GB MSATA MLC SATAIII 3.3V

Technical Specifications

Parameters and characteristics for this part

Specification	EXSAM1B256GB0M1I00

Form Factor	mSATA
Memory Size	256 GB
Memory Type	Solid State Drive (SSD) FLASH - NAND (MLC)
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Size / Dimension [x]	2 in
Size / Dimension [y]	29.85 mm
Size / Dimension [z]	3.4 mm
Speed - Read	540 MB/s
Speed - Write	520 MB/s
Type	SATA III
Voltage - Supply	3.3 V

Part	Speed - Read	Form Factor	Voltage - Supply	Speed - Write	Operating Temperature [Max]	Operating Temperature [Min]	Memory Size	Memory Type	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Type
ExAscend EXSAM1B256GB0M1I00	540 MB/s	mSATA	3.3 V	520 MB/s	85 °C	-40 °C	256 GB	Solid State Drive (SSD) FLASH - NAND (MLC)	2 in	3.4 mm	29.85 mm	SATA III

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Solid State Drive (SSD) FLASH - NAND (MLC) 256GB SATA III mSATA 3.3V

Technical documentation and resources

No documents available
