HRPG-150-5

Active

MEAN WELL USA Inc.

AC/DC CONVERTER 5V 130W

Search across all available documentation for this part.

Active

MEAN WELL USA Inc.

AC/DC CONVERTER 5V 130W

Technical Specifications

Parameters and characteristics for this part

Specification	HRPG-150-5

Applications	ITE (Commercial)
Approval Agency	CB, CE, cURus, TUV
Current - Output 1	26 A
Efficiency	84 %
Features	Universal Input, Remote Sense, Remote On/Off, Adjustable Output, PFC
Minimum Load Required	False
Mounting Type	Chassis Mount
Number of Outputs	1
Power (Watts)	130 W
Size / Dimension [x]	6.26 in
Size / Dimension [x]	159 mm
Size / Dimension [y]	97 mm
Size / Dimension [y]	3.82 in
Size / Dimension [z]	1.5 "
Size / Dimension [z]	38 mm
Type	Enclosed
Voltage - Input [Max]	370 VDC, 264 VAC
Voltage - Input [Min]	85 VAC, 120 VDC
Voltage - Isolation	3000 V
Voltage - Output 1	5 V

Part	Minimum Load Required	Voltage - Isolation	Mounting Type	Applications	Features	Type	Efficiency	Approval Agency	Voltage - Input [Min]	Voltage - Input [Max]	Voltage - Output 1	Current - Output 1	Power (Watts)	Number of Outputs	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]
MEAN WELL USA Inc. HRPG-150-36		3000 V	Chassis Mount	ITE (Commercial)	Adjustable Output PFC Remote On/Off Remote Sense Universal Input	Enclosed	88 %	CB CE cURus TUV	85 VAC 120 VDC	264 VAC 370 VDC	36 V	4.3 A	155 W	1	97 mm	1.5 "	6.26 in	38 mm	159 mm	3.82 in
MEAN WELL USA Inc. HRPG-150-5		3000 V	Chassis Mount	ITE (Commercial)	Adjustable Output PFC Remote On/Off Remote Sense Universal Input	Enclosed	84 %	CB CE cURus TUV	85 VAC 120 VDC	264 VAC 370 VDC	5 V	26 A	130 W	1	97 mm	1.5 "	6.26 in	38 mm	159 mm	3.82 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Enclosed AC DC Converters 1 Output 5V 85 ~ 264 VAC, 120 ~ 370 VDC Input
